Airtac MSBL Aluminum Alloy Mini Cylinder MSBL20X100CA
2. Riveted aluminum-clad structure integrates end caps with aluminum alloy barrel for superior connection integrity;
3. Proprietary bidirectional asymmetric seal design with compact dimensions and integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Comprehensive range of cylinder configurations and mounting accessories available for client customization.
Category: Aluminum Miniature Cylinders , Brand: AIRTAC , Series: MSBL
AirTAC MSBL20X100CA Aluminum Miniature Cylinder Specifications
- Model: MSBL20X100CA
- Bore size: 20mm
- Stroke: 100mm
- Operation type: Double-acting (with magnetic piston)
- Working pressure: 0.05-1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion
- Mounting types: Basic foot, front flange, rear flange, or side-mounted
- Port size: M5x0.8 (standard) or NPT1/8 (optional)
- Piston material: Aluminum alloy with hard anodized surface
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (nitrile rubber)
- Weight: 0.65kg (without accessories)
- Dimensions: 145mm(L) × 32mm(W) × 32mm(H) (extended length)
- ISO standard: 6432 (mounting dimensions compatible)
- Max theoretical thrust: 31.4kgf at 0.6MPa
- Lubrication: Pre-lubricated (oil-free operation possible)
Ultra-compact cylinder featuring anti-rotation mechanism and built-in magnet for position sensing. The hard anodized barrel provides superior wear resistance and corrosion protection. Designed for high-duty cycles (up to 5 million strokes) with 1μm filtered air. Optional auto switch models available (D-M9N series).
- PCB handling robots in electronics manufacturing
- Precision clamping in CNC tool changers
- Actuation in medical analyzer equipment
- Small parts ejection systems
- Semiconductor wafer processing machines
- Laboratory automation positioning
Installation tip:
Maintain 0.5-1mm clearance between magnetic sensor and cylinder body.
For vertical mounting, use speed controller to prevent piston free-fall.
Lubricate every 3 months with ISO VG32 hydraulic oil if used in oil mist lubrication systems.
| Property | Property Value |
|---|---|
| sku | MSBL20X100CA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
