Airtac MSBL Aluminum Alloy Mini Cylinder MSBL20X100SCA
2. Riveted aluminum-clad structure integrates end caps with aluminum alloy barrel for superior connection integrity;
3. Proprietary bidirectional asymmetric seal design with compact dimensions and integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Comprehensive range of cylinder configurations and mounting accessories available for client customization.
Category: Aluminum Miniature Cylinders , Brand: AIRTAC , Series: MSBL
AirTAC MSBL Series Aluminum Miniature Cylinder MSBL20X100SCA Specifications
- Model: MSBL20X100SCA
- Bore Size: 20mm
- Stroke: 100mm
- Operation: Double-acting
- Operating Pressure: 0.15-0.8 MPa (21.7-116 psi)
- Cushion Type: Rubber buffer + adjustable cushion screw
- Mounting Style: Front flange (SCA code)
- Port Size: M5x0.8 (standard) with NPT1/8 adapter optional
- Material:
- Tube: Aluminum alloy (hard anodized)
- Piston Rod: Stainless steel (SUS304)
- Seals: Nitrile rubber (NBR)
- Temperature Range: -20℃ to 80℃ (-4°F to 176°F)
- Piston Speed: 50-700 mm/s (optimal range)
- Protection Class: IP65 (standard wiper design)
- Cushion Length: 12mm (both ends)
- Weight: 420g ±3% (without accessories)
- Dimensions:
- Total Length: 144mm (at full retraction)
- Body Diameter: Φ32mm
- Flange Mounting Base: 40mm x 40mm
- Rod End Thread: M10x1.25
Ultra-compact aluminum cylinder featuring a space-saving design with 35% reduced length compared to standard models. The hard-coated barrel surface minimizes friction loss, while the dual cushion system ensures smooth end-stroke deceleration. Includes built-in magnet for sensor mounting (ISO 21287 compliant). Requires 5μm filtered lubricated air (ISO 8573-1).
- Robotic gripper mechanisms in assembly lines
- Precision positioning in semiconductor handling
- Medical device actuation systems
- Compact packaging machinery
- Automated test equipment (ATE) fixtures
Installation tip:
Maintain 0.5-1mm clearance between cylinder body and mounting surface for thermal expansion.
Use only brass fittings to prevent galvanic corrosion with aluminum body.
- Relubrication interval: Every 500km cumulative stroke distance
- Wiper replacement: Every 1 million cycles
- Full overhaul: After 5 million cycles or 3 years (whichever comes first)
| Property | Property Value |
|---|---|
| sku | MSBL20X100SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
