Airtac MSBL Aluminum Alloy Mini Cylinder MSBL20X100SU
2. Riveted aluminum-clad structure integrates end caps with aluminum alloy barrel for superior connection integrity;
3. Proprietary bidirectional asymmetric seal design with compact dimensions and integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Comprehensive range of cylinder configurations and mounting accessories available for client customization.
Category: Aluminum Miniature Cylinders , Brand: AIRTAC , Series: MSBL
AirTAC MSBL Series Aluminum Miniature Cylinder MSBL20X100SU Technical Details
- Model Code: MSBL20X100SU
- Bore Size: 20mm (ISO 6432 standard)
- Stroke: 100mm (adjustable stroke available)
- Action Type: Double-acting
- Operating Pressure: 0.05-1.0 MPa
- Cushioning: Adjustable pneumatic cushioning (both ends)
- Port Size: M5x0.8 (standard) / NPT1/8 optional
- Piston Speed: 50-800 mm/s
- Ambient Temperature: -20℃ to 80℃
- Seal Material: NBR (Nitrile) with wear-resistant ring
- Magnet Type: Built-in magnetic sensor slot (Reed switch compatible)
- Mounting: Standard ISO 15552 front flange with 4xM5 threads
- Rod End: Female thread M6x1.0
- Weight: 0.45kg ±2% (without accessories)
- Dimensions: 180mm(L) x 32mm(W) x 35mm(H) (full extension)
- Rod Thread Depth: 10mm
- Repeat Positioning Accuracy: ±0.5mm
- Protection Class: IP54 (standard) / IP67 (optional wiper upgrade)
Ultra-compact aluminum cylinder optimized for space-constrained automation systems. Features precision-machined anodized barrel for corrosion resistance and low-friction operation. Integrated cushioning adjustment screws allow fine-tuning of end-stroke deceleration. The SU variant includes enhanced sealing for vacuum applications (down to -95kPa).
- PCB handling robots in electronics assembly
- Precision clamping mechanisms in CNC tool changers
- Medical device actuator systems (IV pump mechanisms)
- Food packaging machine pusher arms
- Laboratory automation sample handlers
- Semiconductor wafer processing equipment
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use. For vertical mounting,
add 15% safety factor to load calculations. Maintain 0.3-1.0 MPa operating pressure
for optimal seal longevity. Avoid side-load forces exceeding 15N.
| Property | Property Value |
|---|---|
| sku | MSBL20X100SU |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
