Airtac MSBL Aluminum Alloy Mini Cylinder MSBL20X10SCA
2. Riveted aluminum-clad structure integrates end caps with aluminum alloy barrel for superior connection integrity;
3. Proprietary bidirectional asymmetric seal design with compact dimensions and integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Comprehensive range of cylinder configurations and mounting accessories available for client customization.
Category: Aluminum Miniature Cylinders , Brand: AIRTAC , Series: MSBL
AirTAC MSBL Aluminum Miniature Cylinder MSBL20X10SCA Specifications
- Model: MSBL20X10SCA
- Type: Single-acting spring return (compact series)
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 10mm (±1mm adjustable)
- Operation: Air pressure extension, spring retraction
- Working pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Port size: M5x0.8 (dual ports with 6mm push-in fittings)
- Cushioning: Rubber buffer (both ends)
- Material: Aluminum alloy body, NBR seals
- Mounting: 2x M4 threaded holes (side mounting standard)
- Weight: 0.25kg (0.55lbs) ±3%
- Dimensions: 70mm(L) × 40mm(W) × 40mm(H)
- Rod thread: M6x1 external thread (piston rod end)
- Max speed: 500mm/s (with cushioning)
- Lubrication: Pre-lubricated (G oil class)
Ultra-compact aluminum cylinder optimized for space-constrained automation systems. Features dual anti-rotation guide slots (ISO 6432 compliant) and corrosion-resistant anodized finish. Spring chamber includes vent filter to prevent contamination. Optional magnetic piston version available for position sensing.
- Semiconductor wafer handling robots
- Pharmaceutical blister packaging machines
- 3D printer filament tensioning mechanisms
- Micro-dosing valve actuators
- Optical lens positioning systems
Installation tip:
For vertical mounting, reduce operating pressure by 20% to compensate for spring force.
Use lock nuts (included) for vibration-prone environments. Minimum 5μm filtration required.
