Airtac MSBL Aluminum Alloy Mini Cylinder MSBL20X10U
2. Riveted aluminum-clad structure integrates end caps with aluminum alloy barrel for superior connection integrity;
3. Proprietary bidirectional asymmetric seal design with compact dimensions and integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Comprehensive range of cylinder configurations and mounting accessories available for client customization.
Category: Aluminum Miniature Cylinders , Brand: AIRTAC , Series: MSBL
AirTAC MSBL Series Aluminum Miniature Cylinder MSBL20X10U Specifications
- Model: MSBL20X10U
- Bore size: 20mm
- Stroke: 10mm
- Structure: Compact U-shaped aluminum alloy body
- Mounting types: Basic/U-shaped bracket (standard)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -20℃ to 80℃ (NBR seals)
- Cushioning: Adjustable pneumatic cushioning
- Port size: 1/8" NPT (M5 optional)
- Piston speed: 50–800 mm/s
- Weight: 0.25 kg (body only), 0.32 kg (with bracket)
- Dimensions: 90mm(L) × 34mm(W) × 48mm(H) (full extension)
- Rod thread: M5×0.8 external thread
- Protection class: IP54 (standard)
- Lubrication: Pre-lubricated (non-re-lube design)
Ultra-compact aluminum cylinder engineered for space-constrained automation systems. Features anodized corrosion-resistant surface and dual anti-rotation guides for precise linear motion. Optimized for low friction operation with self-compensating wear resistance. Requires 5μm filtered compressed air (non-lubricated air acceptable).
- PCB handling robots in electronics assembly
- Precision clamping mechanisms in medical devices
- Compact sorting gates in food packaging lines
- Valve actuation in semiconductor manufacturing
- Miniature press systems in jewelry production
Installation note:
Maximum side load ≤5N. For vertical mounting, use speed controller to prevent piston overstroke.
Avoid direct exposure to cutting fluids - use protective bellows (accessory MAB20) in wet environments.
| Property | Property Value |
|---|---|
| sku | MSBL20X10U |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
