Airtac MSBL Aluminum Alloy Mini Cylinder MSBL20X125CA
2. Riveted aluminum-clad structure integrates end caps with aluminum alloy barrel for superior connection integrity;
3. Proprietary bidirectional asymmetric seal design with compact dimensions and integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Comprehensive range of cylinder configurations and mounting accessories available for client customization.
Category: Aluminum Miniature Cylinders , Brand: AIRTAC , Series: MSBL
AirTAC MSBL20X125CA Aluminum Mini Cylinder Specifications
- Model: MSBL20X125CA
- Bore size: 20mm
- Stroke: 125mm
- Action type: Double-acting
- Material: Anodized aluminum alloy (barrel), Stainless steel (piston rod)
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Mounting type: CA series (Front flange with threaded installation)
- Port size: M5×0.8 (Standard) / NPT1/8 (Optional)
- Piston speed: 50–800 mm/s
- Weight: 480g ±5%
- Dimensions:
- Extended length: 185mm
- Retracted length: 60mm
- Body diameter: 32mm
- Mounting flange width: 45mm
- Seal material: NBR (Nitrile rubber)
- ISO standard: 6432
Ultra-compact pneumatic cylinder featuring precision machining and wear-resistant construction. The anodized surface treatment provides enhanced corrosion resistance for humid environments. Optimized flow path design ensures smooth operation at both high and low speeds. Includes magnetic piston for position sensing compatibility.
- PCB handling robots in electronics manufacturing
- Precision clamping mechanisms in CNC tool changers
- Paper feed systems in high-speed printers
- Laboratory sample sorting equipment
- Pharmaceutical blister packaging machines
Installation notes:
- Use clean, dry air with 40μm filtration
- Apply micro-lubrication (ISO VG32) for initial operation
- Align piston rod within 0.5° angular misalignment tolerance
- Allow 15mm clearance behind magnetic sensor slots
| Property | Property Value |
|---|---|
| sku | MSBL20X125CA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
