Airtac MSBL Aluminum Alloy Mini Cylinder MSBL20X125SCA
2. Riveted aluminum-clad structure integrates end caps with aluminum alloy barrel for superior connection integrity;
3. Proprietary bidirectional asymmetric seal design with compact dimensions and integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Comprehensive range of cylinder configurations and mounting accessories available for client customization.
Category: Aluminum Miniature Cylinders , Brand: AIRTAC , Series: MSBL
AirTAC MSBL Series Aluminum Miniature Cylinder MSBL20X125SCA Specifications
- Model: MSBL20X125SCA
- Bore size: 20mm
- Stroke: 125mm (±0.5mm tolerance)
- Action type: Double-acting
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃ (dry air required below 0℃)
- Cushioning: Adjustable rubber buffer + air cushion
- Mounting style: Basic type (optional foot/mid-flange)
- Port size: M5x0.8 (standard) or NPT1/8 (optional)
- Piston rod thread: M6x1 (external)
- Material: Aluminum alloy body (anodized), CR12MoV piston rod
- Seal material: NBR (standard) / VITON (optional)
- Protection rating: IP54 (standard), IP67 w/ wiper upgrade
- Accessories: Built-in magnet for sensor attachment
- Weight: 540g ±2% (without accessories)
- Dimensions:
- Length: 196mm (full extension)
- Body diameter: 32mm
- Mounting hole spacing: 25mm (front) / 40mm (rear)
Precision-engineered compact cylinder featuring hard anodized aluminum construction with chromium-plated piston rod. The dual cushioning system ensures smooth end-stroke deceleration, while the multi-lip wiper seal maintains contamination resistance. Compatible with all major magnetic proximity sensors (2mm detection distance).
- High-density PCB component insertion machines
- Pharmaceutical blister packaging systems
- 3D printer automatic bed leveling mechanisms
- Semiconductor wafer handling robots
- Food-grade production line actuators
Installation notes:
- Maximum side load: 15N at full extension
- Lubrication: Pre-lubricated (relubrication interval: 2,000km travel)
- For vertical mounting, maintain ≥0.3MPa pressure to prevent seal wear
| Property | Property Value |
|---|---|
| sku | MSBL20X125SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
