Airtac MSBL Aluminum Alloy Mini Cylinder MSBL20X125SU
2. Riveted aluminum-clad structure integrates end caps with aluminum alloy barrel for superior connection integrity;
3. Proprietary bidirectional asymmetric seal design with compact dimensions and integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Comprehensive range of cylinder configurations and mounting accessories available for client customization.
Category: Aluminum Miniature Cylinders , Brand: AIRTAC , Series: MSBL
AirTAC MSBL Series Aluminum Miniature Cylinder MSBL20X125SU
- Model: MSBL20X125SU
- Bore size: 20mm
- Stroke: 125mm
- Action type: Double acting
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to +80℃
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: M5x0.8 (standard), optional NPT1/8
- Mounting type: Basic foot mounting (ISO 6432 compatible)
- Magnet type: Built-in magnetic sensor slot (Reed switch compatible)
- Piston rod material: Stainless steel (SUS304)
- Seal material: NBR (Nitrile rubber)
- Weight: 0.62kg (excluding accessories)
- Dimensions: 165mm(L) × 26mm(W) × 26mm(H) (fully retracted)
- Max theoretical thrust: 31.4N at 0.63MPa
- Max speed: 500mm/s
- ISO standard: 6432/VDMA 24562
Ultra-compact aluminum cylinder optimized for space-constrained automation systems. Features precision honed bore with hard anodized surface treatment (15-25μm) for wear resistance. The SU variant includes a magnetic piston for position sensing and dual cushioning adjustment screws with locknuts. Sealed against IP54 particulate ingress protection.
- PCB handling robots in electronics assembly
- Pharmaceutical blister packaging machines
- Semiconductor wafer processing equipment
- Compact clamping fixtures for CNC tooling
- Medical analyzer reagent handling systems
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use. Avoid side load forces exceeding 2N·m.
For vertical mounting, use anti-rotation brackets (optional accessory MBK-20). Maintain 0.5mm
minimum clearance around magnetic sensor surfaces.
| Property | Property Value |
|---|---|
| sku | MSBL20X125SU |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
