Airtac MSBL Aluminum Alloy Mini Cylinder MSBL20X150CA
2. Riveted aluminum-clad structure integrates end caps with aluminum alloy barrel for superior connection integrity;
3. Proprietary bidirectional asymmetric seal design with compact dimensions and integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Comprehensive range of cylinder configurations and mounting accessories available for client customization.
Category: Aluminum Miniature Cylinders , Brand: AIRTAC , Series: MSBL
AirTAC MSBL Series Aluminum Miniature Cylinder MSBL20X150CA Specifications
- Model: MSBL20X150CA
- Type: Single-acting spring return (normally closed)
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 150mm (±0.5mm tolerance)
- Operating pressure: 0.05–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Mounting type: Basic type (no built-in mounting)
- Port size: M5x0.8 threaded
- Piston rod thread: M6x1 external thread
- Material: Aluminum alloy body (anodized), CR12MoV piston rod
- Seal material: NBR (nitrile rubber)
- Weight: 0.45kg (excluding accessories)
- Dimensions: 210mm(L) × 28mm(Ø) × 28mm(H) (cylinder body only)
- Stroke tolerance: ±1.5mm (per 100mm stroke)
- Max theoretical thrust: 25.1N @0.5MPa
Ultra-compact pneumatic cylinder featuring corrosion-resistant aluminum construction with precision ground piston rod. The dual-purpose mounting slots allow flexible installation configurations. Requires minimal lubrication (1 drop of ISO VG32 oil per 1 million cycles). Built-in magnetic sensor slot (non-embedded type) for position detection compatibility.
- PCB handling robots in electronics assembly
- Medical device actuation mechanisms
- Textile machinery thread control systems
- Laboratory automation sample handlers
- Food packaging vertical lift mechanisms
Installation note:
Maintain 0.5-1mm clearance between rod end and load during alignment.
For vertical mounting, use spring-down orientation to prevent seal wear.
Maximum side load: 3N at full extension.
| Property | Property Value |
|---|---|
| sku | MSBL20X150CA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 150mm |
