Airtac MSBL Aluminum Alloy Mini Cylinder MSBL20X150SCA
2. Riveted aluminum-clad structure integrates end caps with aluminum alloy barrel for superior connection integrity;
3. Proprietary bidirectional asymmetric seal design with compact dimensions and integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Comprehensive range of cylinder configurations and mounting accessories available for client customization.
Category: Aluminum Miniature Cylinders , Brand: AIRTAC , Series: MSBL
AirTAC MSBL20X150SCA Aluminum Miniature Cylinder Specifications
- Model: MSBL20X150SCA
- Type: Single-acting spring return (with magnetic piston)
- Bore size: 20mm
- Stroke: 150mm
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (dual ports)
- Cushion type: Adjustable buffer
- Mounting style: Foot-mounted (ISO 6432 standard)
- Material: Anodized aluminum alloy body
- Seal material: NBR (Nitrile rubber)
- Weight: 0.68kg (with accessories)
- Dimensions: 200mm(L) × 34mm(W) × 34mm(H) (at full extension)
- Piston rod thread: M6x1.0
- Max theoretical thrust: 63N @0.6MPa
- Repeat positioning accuracy: ±0.5mm
- Magnetic sensor compatibility: D-A93 series
Ultra-compact pneumatic cylinder with integrated magnetic field for position sensing. Features hard-anodized aluminum construction for corrosion resistance and lightweight operation (40% lighter than steel cylinders). The double-chamber buffer design minimizes end-impact noise. Optimized for high-speed reciprocating motion up to 1.5m/s.
- PCB handling robots in electronics assembly
- Precision clamping mechanisms in CNC tool changers
- Cartesian coordinate actuators for 3D printing
- Medical device positioning systems
- Automated test equipment sample handlers
Installation guidelines:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain 0.3-1mm clearance between magnetic sensor and cylinder body.
Avoid side-load forces exceeding 15N. For vertical mounting,
use spring-return side as upward direction.
| Property | Property Value |
|---|---|
| sku | MSBL20X150SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 150mm |
