Airtac MSBL Aluminum Alloy Mini Cylinder MSBL20X150SU
2. Riveted aluminum-clad structure integrates end caps with aluminum alloy barrel for superior connection integrity;
3. Proprietary bidirectional asymmetric seal design with compact dimensions and integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Comprehensive range of cylinder configurations and mounting accessories available for client customization.
Category: Aluminum Miniature Cylinders , Brand: AIRTAC , Series: MSBL
AirTAC MSBL20X150SU Aluminum Miniature Cylinder Specifications
- Model: MSBL20X150SU
- Series: MSBL (Aluminum Mini Cylinder)
- Bore size: 20mm
- Stroke: 150mm
- Action type: Double-acting with magnetic piston
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable buffer at both ends
- Port size: M5x0.8 (1/8" NPT optional)
- Piston rod material: Stainless steel (SUS304)
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Mounting types: Basic, front flange, foot mounting
- Sensor compatibility: Built-in magnet for reed switch sensors
- Weight: 0.48kg (1.06 lbs)
- Dimensions: 200mm(L) × 40mm(W) × 40mm(H)
- Rod end: M6x1 external thread
- Max speed: 500mm/s
- ISO standard: 6432 (mounting dimensions compliant)
Ultra-compact pneumatic cylinder optimized for space-constrained automation systems. Features corrosion-resistant construction with precision honed tube and chrome-plated piston rod. The integrated magnetic field enables position feedback when paired with sensors. Anti-rotation design maintains orientation during operation.
- PCB handling robots in electronics manufacturing
- Medical analyzer sample tray positioning
- Automated packaging machine grippers
- Precision valve actuation in semiconductor equipment
- Banknote processing machine mechanisms
Installation tips:
Use alignment jigs during mounting to prevent side load. Lubricate with ISO VG32 hydraulic oil
before initial operation. For vertical installations exceeding 45° angle, add mechanical
locking or counterbalance valve.
| Property | Property Value |
|---|---|
| sku | MSBL20X150SU |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 150mm |
