Airtac MSBL Aluminum Alloy Mini Cylinder MSBL20X15SCA
2. Riveted aluminum-clad structure integrates end caps with aluminum alloy barrel for superior connection integrity;
3. Proprietary bidirectional asymmetric seal design with compact dimensions and integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Comprehensive range of cylinder configurations and mounting accessories available for client customization.
Category: Aluminum Miniature Cylinders , Brand: AIRTAC , Series: MSBL
AirTAC MSBL20X15SCA Aluminum Miniature Cylinder Specifications
- Model: MSBL20X15SCA
- Type: Single-acting spring return (push type)
- Bore size: 20mm
- Stroke: 15mm
- Operating pressure: 0.15–0.8 MPa
- Ambient temperature: -20℃ to +80℃
- Cushioning: Rubber buffer (adjustable)
- Mounting style: Basic type (no built-in mounting)
- Port size: M5x0.8 (1/8" NPT optional)
- Material: Anodized aluminum alloy body
- Seal material: Heat-resistant NBR
- Protection rating: IP67 (dust-tight & protected against temporary immersion)
- Weight: 0.25kg (without accessories)
- Dimensions: 70mm(L) × 40mm(W) × 40mm(H) (at fully retracted position)
- Rod thread: M5x0.8 female thread
- Max theoretical thrust: 78.5N @0.6MPa
- Piston speed: 50–700mm/s
Ultra-compact aluminum cylinder designed for space-constrained automation systems. Features hard anodized surface treatment for enhanced corrosion resistance and a double-sealed piston structure for reliable leak prevention. The T-slot design on multiple surfaces allows flexible sensor mounting. Optimal for high-frequency operations up to 5 cycles/second.
- PCB handling robots in electronics assembly
- Dosing mechanisms in medical analyzers
- Precision clamping in watchmaking machinery
- Valve actuation in compact fluid control systems
- Cleanroom automation in semiconductor manufacturing
Installation guidelines:
Lubricate with ISO VG32 hydraulic oil before initial use. Avoid side load exceeding 2N.
For vertical mounting, use stroke-end locking nuts (sold separately). Maintain 0.5mm minimum
clearance between rod end and workpiece during impact operations.
| Property | Property Value |
|---|---|
| sku | MSBL20X15SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <15mm> |
