Airtac MSBL Aluminum Alloy Mini Cylinder MSBL20X15U
2. Riveted aluminum-clad structure integrates end caps with aluminum alloy barrel for superior connection integrity;
3. Proprietary bidirectional asymmetric seal design with compact dimensions and integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Comprehensive range of cylinder configurations and mounting accessories available for client customization.
Category: Aluminum Miniature Cylinders , Brand: AIRTAC , Series: MSBL
AirTAC MSBL20X15U Aluminum Mini Cylinder Technical Details
- Model: MSBL20X15U
- Bore size: 20mm
- Stroke: 15mm
- Action type: Double-acting
- Material: Anodized aluminum alloy (body), CR12MoV steel (piston rod)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer (both ends)
- Port size: M5x0.8 (standard) with NPT1/8 adaptor optional
- Rod end: Female thread M5x0.8
- Seal material: High-grade NBR (nitrile rubber)
- Weight: 0.23kg (bare cylinder), 0.28kg (with accessories)
- Dimensions:
- Length (retracted): 70mm
- Extended length: 85mm
- Body diameter: 32mm
- Mounting base: 20×20mm square pattern
- ISO standard: 6432 compliant
- Lubrication: Pre-lubricated (maintenance-free operation)
Ultra-compact pneumatic cylinder featuring anti-corrosion hard anodized surface treatment and precision honed bore. The T-slot mounting design enables 360° adjustable positioning, while the dual cushioning system reduces impact noise to below 75dB. Compatible with vacuum applications when paired with appropriate seals.
- Medical device actuation (infusion pumps, dental chairs)
- Semiconductor handling robots
- Food packaging machinery (FDA-compliant version available)
- Automated optical inspection systems
- Cleanroom environments (low particle emission design)
Installation pro tip:
For vertical mounting applications exceeding 0.6MPa, install a mechanical position lock.
Always use swivel joints to prevent side load forces – maximum permissible lateral
force is 4.9N at full extension.
| Property | Property Value |
|---|---|
| sku | MSBL20X15U |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | <15mm> |
