Airtac MSBL Aluminum Alloy Mini Cylinder MSBL20X20SCA
$25.35
Regular price
$32.85
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MSBL20X20SCA
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with AIRTAC corporate standards, utilizing extruded aluminum round tube barrel construction;
2. Riveted aluminum-clad structure integrates end caps with aluminum alloy barrel for superior connection integrity;
3. Proprietary bidirectional asymmetric seal design with compact dimensions and integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Comprehensive range of cylinder configurations and mounting accessories available for client customization.
Category: Aluminum Miniature Cylinders , Brand: AIRTAC , Series: MSBL
Installation guidelines:
For optimal performance, maintain rod alignment within ±2° angular misalignment.
Use ISO VG32 hydraulic oil mist lubrication (0.5-1.0cc/m³). Avoid side load exceeding 5N.
Recommended cycle rate: ≤15 cycles/minute for extended seal life.
2. Riveted aluminum-clad structure integrates end caps with aluminum alloy barrel for superior connection integrity;
3. Proprietary bidirectional asymmetric seal design with compact dimensions and integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Comprehensive range of cylinder configurations and mounting accessories available for client customization.
Category: Aluminum Miniature Cylinders , Brand: AIRTAC , Series: MSBL
AirTAC MSBL20X20SCA Aluminum Miniature Cylinder Specifications
- Model: MSBL20X20SCA
- Type: Single-acting spring return (push type)
- Bore size: 20mm
- Stroke: 20mm (±1mm)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Elastic buffer + adjustable stopper
- Mounting style: Basic (axial foot/rod flange optional)
- Port size: M5x0.8 (G1/8 adaptor available)
- Rod material: Stainless steel (SUS304)
- Body material: Anodized aluminum alloy
- Seal material: NBR/PU hybrid seals
- Weight: 0.25kg (without accessories)
- Dimensions: 100mm(L) × 20mm(W) × 20mm(H) (at full retraction)
- Rod thread: M6x1.0 external thread
- Max speed: 500mm/s
- ISO standard: 6432
Ultra-compact pneumatic cylinder featuring anti-rotation design and dual sealing system. The precision-ground piston rod and hard-anodized barrel ensure low friction coefficient (μ≤0.15) and IP54 dust/water protection. Includes built-in magnet for position sensing compatibility.
Typical Applications:
- Semiconductor wafer handling robots
- Pharmaceutical blister packaging machines
- Mobile laboratory analyzer mechanisms
- Automated coffee machine brew units
- PCB optical inspection equipment
Installation guidelines:
For optimal performance, maintain rod alignment within ±2° angular misalignment.
Use ISO VG32 hydraulic oil mist lubrication (0.5-1.0cc/m³). Avoid side load exceeding 5N.
Recommended cycle rate: ≤15 cycles/minute for extended seal life.
Optional accessories:
MMF-20 magnetic sensor kit, SCS-20 rod clevis, ARB-20 auto switch bracket
| Property | Property Value |
|---|---|
| sku | MSBL20X20SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <20mm> |
