Airtac MSBL Aluminum Alloy Mini Cylinder MSBL20X20U
2. Riveted aluminum-clad structure integrates end caps with aluminum alloy barrel for superior connection integrity;
3. Proprietary bidirectional asymmetric seal design with compact dimensions and integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Comprehensive range of cylinder configurations and mounting accessories available for client customization.
Category: Aluminum Miniature Cylinders , Brand: AIRTAC , Series: MSBL
AirTAC MSBL20X20U Aluminum Mini Cylinder Technical Details
- Model: MSBL20X20U
- Bore size: 20mm
- Stroke: 20mm (±1mm adjustable)
- Material: Anodized aluminum alloy (6063-T5)
- Mounting type: Standard U-shaped base with 4x M4 threaded holes
- Operating pressure: 0.1-0.9 MPa (14.5-130.5 PSI)
- Cushioning: Adjustable rubber buffer (both ends)
- Piston speed: 50-750 mm/s (lubricated)
- Port size: M5x0.8 (G1/8 NPT optional)
- Ambient temperature: -20℃ to 80℃ (-4℉ to 176℉)
- Seal material: NBR/PU hybrid seals
- Rod material: Stainless steel (SUS304)
- Weight: 0.25kg (without accessories)
- Dimensions: 62mm(L) × 28mm(W) × 28mm(H) (base to rod end)
- ISO standard: Compliant with ISO 6432 mounting dimensions
- Magnet switch: Compatible with SNS-L series sensors
Ultra-compact pneumatic cylinder featuring space-saving design with 45% reduced footprint compared to standard cylinders. The hard-anodized barrel provides exceptional corrosion resistance for humid environments. Integrated buffer adjustment screws allow precise end-position deceleration control. Optional auto switch groove enables position feedback integration.
- High-density automation equipment (PCB handlers, chip sorters)
- Medical device actuators requiring precise linear motion
- Cleanroom applications (ESD-safe version available)
- Packaging machinery with limited mounting space
- Educational robotics projects
- Beverage dispensing systems
Maintenance tip:
Lubricate every 500,000 cycles using ISO VG32 turbine oil.
Avoid side load exceeding 2N·m. For vertical installations,
use speed controller (ASC-06) to prevent piston slam.
| Property | Property Value |
|---|---|
| sku | MSBL20X20U |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | <20mm> |
