Airtac MSBL Aluminum Alloy Mini Cylinder MSBL20X25SCA
2. Riveted aluminum-clad structure integrates end caps with aluminum alloy barrel for superior connection integrity;
3. Proprietary bidirectional asymmetric seal design with compact dimensions and integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Comprehensive range of cylinder configurations and mounting accessories available for client customization.
Category: Aluminum Miniature Cylinders , Brand: AIRTAC , Series: MSBL
AirTAC MSBL Series Aluminum Miniature Cylinder MSBL20X25SCA Specifications
- Model: MSBL20X25SCA
- Type: Single-acting spring return (mini cylinder)
- Bore size: 20mm
- Stroke: 25mm (±1.5mm tolerance)
- Operating pressure: 0.15-0.8 MPa
- Temperature range: -20℃ to 80℃
- Port thread: M5×0.8 (standard) / 1/8 NPT optional
- Cushioning: Adjustable rubber buffer
- Material: Aluminum alloy body (anodized) + CRMo steel piston rod
- Seal material: NBR (Nitrile rubber)
- Mounting style: Basic type (optional foot/mounting flange)
- Weight: 0.19kg (without accessories)
- Dimensions: 100mm(L) × 20mm(W) × 20mm(H) (retracted position)
Ultra-compact pneumatic cylinder featuring precision honed tubing and dual anti-rotation guide slots. The lightweight aluminum construction (58% lighter than steel cylinders) enables high-speed operation up to 1.5m/s. Includes built-in magnet for position sensing compatibility. Requires ISO VG32 or equivalent lubrication oil (drip feed or mist).
- PCB handling robots in electronics assembly
- Micro-part ejection in injection molding machines
- Valve actuation in portable medical analyzers
- Precision clamping in watchmaking/jewelry fixtures
- Automated lens positioning in optical equipment
Installation tip:
For vertical mounting, reduce maximum speed by 30% to prevent piston rod buckling.
Maintain 0.5mm minimum clearance between rod end and workpiece during alignment.
| Property | Property Value |
|---|---|
| sku | MSBL20X25SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <25 mm> |
