Airtac MSBL Aluminum Alloy Mini Cylinder MSBL20X25U
2. Riveted aluminum-clad structure integrates end caps with aluminum alloy barrel for superior connection integrity;
3. Proprietary bidirectional asymmetric seal design with compact dimensions and integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Comprehensive range of cylinder configurations and mounting accessories available for client customization.
Category: Aluminum Miniature Cylinders , Brand: AIRTAC , Series: MSBL
AirTAC MSBL20X25U Aluminum Miniature Cylinder Specifications
- Model: MSBL20X25U
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 25mm (adjustable cushioning)
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-800 mm/s
- Ambient temperature: -20℃ to 80℃
- Mounting type: Universal (front flange + rear foot)
- Cushioning: Rubber buffer (adjustable end caps)
- Port size: M5x0.8 (standard) or NPT1/8 (optional)
- Rod end: Female thread M6x1.0
- Seal material: Nitrile rubber (NBR)
- Weight: 0.34 kg (without accessories)
- Dimensions: 85mm(L) × 34mm(W) × 34mm(H)
- ISO certification: 6432/DIN ISO 15552 compliant
Ultra-compact aluminum cylinder featuring anodized corrosion resistance and precision honed tube. The dual-cushion design minimizes end-impact noise while maintaining positioning accuracy (±0.5mm repeatability). Optimized for high-duty cycle operations with 5 million stroke lifespan under standard conditions. Requires filtered air with 5-40μm filtration.
- PCB handling robots in electronics manufacturing
- Pharmaceutical blister packaging machines
- Lens positioning in optical inspection systems
- Automated coffee machine actuators
- Semiconductor wafer transfer mechanisms
Installation recommendation:
Use locknuts (ASNU6) for vibration-prone environments. Lubricate through
air supply (ISO VG32 oil mist) if operating below 0.3 MPa. Maintain minimum
2mm lateral clearance during alignment.
| Property | Property Value |
|---|---|
| sku | MSBL20X25U |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | <25 mm> |
