Airtac MSBL Aluminum Alloy Mini Cylinder MSBL20X30CA
2. Riveted aluminum-clad structure integrates end caps with aluminum alloy barrel for superior connection integrity;
3. Proprietary bidirectional asymmetric seal design with compact dimensions and integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Comprehensive range of cylinder configurations and mounting accessories available for client customization.
Category: Aluminum Miniature Cylinders , Brand: AIRTAC , Series: MSBL
AirTAC MSBL Series Aluminum Miniature Cylinder MSBL20X30CA Technical Details
- Model: MSBL20X30CA
- Type: Double-acting with magnetic piston (detectable by sensors)
- Bore size: 20mm (±0.1mm manufacturing tolerance)
- Stroke: 30mm (adjustable stroke version available as MSBL20X30CAB)
- Operation: Air pressure 0.15-0.8 MPa (21.7-116 psi)
- Temperature range: -20℃ to 80℃ (NBR seals)/-10℃ to 80℃ (FKM seals optional)
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting types: Basic type (accessory mount kit required) / Front flange (MF) / Side mount (MS)
- Port size: M5x0.8 (standard) / NPT1/8 available on request
- Piston rod thread: M6x1 external thread (stainless steel)
- Seal material: Standard NBR / Optional FKM for chemical resistance
- Protection rating: IP40 (standard) / IP67 with optional wiper seal
- Weight: 0.42kg (bare cylinder) / 0.48kg with magnetic sensor slot
- Dimensions: 90mm(L) x 34mm(W) x 34mm(H) (fully retracted)
- Max theoretical force: 94N at 0.6MPa (extending) / 81N at 0.6MPa (retracting)
- ISO standard: Complies with ISO 6432 mounting dimensions
Ultra-compact aluminum cylinder with integrated magnetic field for position feedback, featuring precision honed tubing and hard anodized piston rod. The MSBL series delivers 0.02mm repeat positioning accuracy through its combination of double lip seals and guided piston design. Optimized for high cycle rates up to 5 cycles/second in clean air environments.
- PCB handling robots in electronics manufacturing
- Valve actuation in analytical instruments
- Clamping mechanisms in micro-machining centers
- Paper feed systems in high-speed printers
- Positioning stages in optical alignment devices
- Vending machine product dispensers
Maintenance protocol:
Lubricate with ISO VG32 turbine oil every 50km of cumulative travel.
Avoid lateral loads exceeding 15N. For vertical mounting,
use guide rails when payload exceeds 0.5kg.
| Property | Property Value |
|---|---|
| sku | MSBL20X30CA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 30mm |
