Airtac MSBL Aluminum Alloy Mini Cylinder MSBL20X30SCA
2. Riveted aluminum-clad structure integrates end caps with aluminum alloy barrel for superior connection integrity;
3. Proprietary bidirectional asymmetric seal design with compact dimensions and integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Comprehensive range of cylinder configurations and mounting accessories available for client customization.
Category: Aluminum Miniature Cylinders , Brand: AIRTAC , Series: MSBL
AirTAC MSBL20X30SCA Aluminum Miniature Cylinder Specifications
- Model: MSBL20X30SCA
- Type: Double-acting compact cylinder with built-in magnet
- Bore size: 20 mm
- Stroke: 30 mm (±1.5mm tolerance)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Cushioning: Rubber buffer with adjustable end-stroke damping
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Material: Anodized aluminum body, stainless steel piston rod
- Seal material: Heat-resistant NBR (Nitrile rubber)
- Port size: M5x0.8 (1/8" NPT optional)
- Protection rating: IP40 (Dust protected)
- Weight: 0.25 kg (0.55 lbs)
- Dimensions: 98mm(L) × 46mm(W) × 46mm(H)
- Piston rod thread: M6x1.0 external thread
- Max theoretical force: 94.2N at 0.6MPa
- Air consumption: 9.42L/min at 0.5MPa (double stroke)
Ultra-compact aluminum cylinder optimized for space-constrained automation systems. Features precision-ground inner bore for smooth operation and minimal stick-slip effect. The integrated magnet enables position sensing compatibility with reed switches or inductive sensors. Corrosion-resistant anodized surface treatment ensures durability in humid environments.
- PCB handling robots in electronics manufacturing
- Medical device actuation systems
- Food packaging machinery (NBR seals FDA-compliant)
- Laboratory automation sample handlers
- Semiconductor wafer processing equipment
- Textile machine thread control mechanisms
Installation guidelines:
Mount using ISO 6432 standard brackets (accessory code MSQUB20).
Maintain ≤0.5mm alignment tolerance during installation.
Lubricate with ISO VG32 hydraulic oil if operating below 3℃.
Avoid side-load forces exceeding 15N.
For vertical mounting, add 20% safety factor to load calculations.
| Property | Property Value |
|---|---|
| sku | MSBL20X30SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 30mm |
