Airtac MSF Single Acting Mini Cylinder MSF20X10SCM
$32.32
Regular price
$39.82
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MSF20X10SCM
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JS industrial standard specifications;
2. Features asymmetric bidirectional piston sealing structure with integrated oil reservoir for compact dimensions;
3. Integrated shock-absorbing pads on both end caps minimize impact during directional changes;
4. Multiple rear cover configurations provide enhanced mounting flexibility;
5. Crimped enclosure design ensures secure assembly between stainless steel cylinder barrel and end caps;
6. High-precision stainless steel tubing construction delivers superior strength and corrosion resistance;
7. Compact design achieves shorter overall length compared to ISO 6432 standard cylinders with equivalent bore size and stroke;
8. Extensive selection of cylinder specifications and mounting accessories available for customized solutions.
Category: Miniature Cylinders , Brand: AIRTAC , Series: MSF
Installation note:
Optimal performance achieved when mounted horizontally. For vertical installations,
use with ≤0.3MPa pressure. Maintain 1mm minimum clearance between magnetic sensor
and cylinder body if using position detection.
2. Features asymmetric bidirectional piston sealing structure with integrated oil reservoir for compact dimensions;
3. Integrated shock-absorbing pads on both end caps minimize impact during directional changes;
4. Multiple rear cover configurations provide enhanced mounting flexibility;
5. Crimped enclosure design ensures secure assembly between stainless steel cylinder barrel and end caps;
6. High-precision stainless steel tubing construction delivers superior strength and corrosion resistance;
7. Compact design achieves shorter overall length compared to ISO 6432 standard cylinders with equivalent bore size and stroke;
8. Extensive selection of cylinder specifications and mounting accessories available for customized solutions.
Category: Miniature Cylinders , Brand: AIRTAC , Series: MSF
AirTAC MSF20X10SCM Single-Acting Mini Cylinder Specifications
- Model: MSF20X10SCM
- Type: Single-acting spring return (push type)
- Bore size: 20mm
- Stroke: 10mm
- Operating pressure: 0.15–0.8 MPa
- Max. thrust: 80N @0.6MPa
- Cushioning: Adjustable rubber bumper
- Port size: M5x0.8 (standard)
- Body material: Aluminum alloy (anodized)
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (nitrile rubber)
- Temperature range: -10℃ to 80℃
- Weight: 160g ±5%
- Dimensions:
- Extended length: 99mm
- Retracted length: 89mm
- Body width: 28mm
- Mounting height: 20mm
- Lubrication: Pre-lubed (Grease-free operation)
- ISO standard: 6432 (mounting compatibility)
Ultra-compact pneumatic cylinder featuring a space-saving design with 40% reduced length compared to standard cylinders. The lightweight aluminum construction and anti-corrosion treatment make it ideal for precision automation in clean environments. Includes magnetic piston for position sensing compatibility (sensor not included).
Typical Applications:
- PCB handling robots in electronics assembly
- Medical device actuation mechanisms
- Photovoltaic panel positioning systems
- Laboratory automation equipment
- Packaging machine ejector mechanisms
- Precision valve actuation in semiconductor tools
Installation note:
Optimal performance achieved when mounted horizontally. For vertical installations,
use with ≤0.3MPa pressure. Maintain 1mm minimum clearance between magnetic sensor
and cylinder body if using position detection.
Service Life:
3,000km stroke distance or 5 million cycles (whichever comes first) under standard
operating conditions (0.5MPa, 20℃, clean air)
| Property | Property Value |
|---|---|
| sku | MSF20X10SCM |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
