Airtac MSI Single Acting Stainless Steel Mini Cylinder MSI10X10CA
2. Front/rear covers with fixed cushion rings to minimize cylinder impact during directional changes;
3. Multiple rear cover configurations for enhanced installation flexibility;
4. Riveted enclosure structure securely connects stainless steel cylinder barrel with end covers;
5. Stainless steel piston rod and cylinder barrel enable operation in mildly corrosive environments;
6. Comprehensive selection of cylinder specifications and mounting accessories available.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MSI
AirTAC MSI Series Single-Acting Stainless Steel Mini Cylinder MSI10X10CA
- Model: MSI10X10CA
- Action type: Single-acting (spring return)
- Material: Stainless steel body (SUS304) + CRNA seal
- Bore size: 10mm
- Stroke: 10mm (±0.5mm adjustability)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 150℃
- Port size: M5x0.8 (standard) with 6mm push-in fitting
- Cushioning: Adjustable rubber bumper
- Mounting style: Basic non-magnetic base (accessory options: MF1/MF2 series mounts)
- Rod thread: M5x0.8 external thread
- Weight: 98g ±2g (excluding accessories)
- Dimensions:
- Length: 89mm (fully retracted)
- Width: 24mm (body diameter)
- Height: 32mm (including mounting base protrusion)
- Lubrication: Pre-lubricated (relubrication interval: 3,000km travel distance)
- ISO standard: Compliant with ISO 6432 (miniature cylinder specifications)
Ultra-compact corrosion-resistant cylinder optimized for precision motion in confined spaces. Features laser-etched identification markings and oxidation-resistant stainless steel construction. The spring-return mechanism provides reliable position retention during pressure loss. Requires 5μm filtered air with maximum particle size ≤50μm.
- Medical device actuation (sterilization-friendly design)
- Semiconductor wafer handling robots
- Food packaging machinery (NSF-compliant materials)
- Micro-positioning in cleanroom environments
- Automated laboratory sample handlers
Installation tip:
For vertical mounting, maintain minimum 0.3MPa pressure to prevent
piston rod sagging. Use locknuts (not included) with mounting bolts
in high-vibration environments.
| Property | Property Value |
|---|---|
| sku | MSI10X10CA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <10mm> |
