Airtac MSI Single Acting Stainless Steel Mini Cylinder MSI10X10SCA
$19.97
Regular price
$27.47
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MSI10X10SCA
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with ISO 6432 standard (φ8~25);
2. Front/rear covers with fixed cushion rings to minimize cylinder impact during directional changes;
3. Multiple rear cover configurations for enhanced installation flexibility;
4. Riveted enclosure structure securely connects stainless steel cylinder barrel with end covers;
5. Stainless steel piston rod and cylinder barrel enable operation in mildly corrosive environments;
6. Comprehensive selection of cylinder specifications and mounting accessories available.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MSI
Installation note:
Maintain 0.5-1mm clearance between piston rod end and load during alignment.
Lubricate with ISO VG32 turbine oil (NBR seal compatible) every 500,000 cycles.
2. Front/rear covers with fixed cushion rings to minimize cylinder impact during directional changes;
3. Multiple rear cover configurations for enhanced installation flexibility;
4. Riveted enclosure structure securely connects stainless steel cylinder barrel with end covers;
5. Stainless steel piston rod and cylinder barrel enable operation in mildly corrosive environments;
6. Comprehensive selection of cylinder specifications and mounting accessories available.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MSI
AirTAC MSI Series Single-Acting Stainless Steel Mini Cylinder MSI10X10SCA
- Model: MSI10X10SCA
- Type: Single-acting (spring return)
- Bore size: 10mm
- Stroke: 10mm
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Material: Stainless steel body (SUS304) + CRMA piston rod
- Cushioning: Rubber pad buffer
- Mounting type: Basic (no pre-mount accessories)
- Protection rating: IP65 (dust-tight & water jet resistant)
- Weight: 0.25kg ±5%
- Dimensions: 65mm(L) × 20mm(W) × 20mm(H) (max extended length)
Ultra-compact stainless steel cylinder designed for precision linear motion in corrosive/clean environments. Features anti-rotation guide slots and integrated mounting threads (M5x0.8). Requires 1-3μm filtered air with ISO 8573-1:2010 class 3.4.2 contaminants standard.
Typical Applications:
- Medical device actuation systems
- Semiconductor wafer handling robots
- Food processing equipment (NSF compliant)
- Optical lens positioning mechanisms
- Laboratory automation sample handlers
Installation note:
Maintain 0.5-1mm clearance between piston rod end and load during alignment.
Lubricate with ISO VG32 turbine oil (NBR seal compatible) every 500,000 cycles.
| Property | Property Value |
|---|---|
| sku | MSI10X10SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <10mm> |
