Airtac MSI Single Acting Stainless Steel Mini Cylinder MSI10X10U
2. Front/rear covers with fixed cushion rings to minimize cylinder impact during directional changes;
3. Multiple rear cover configurations for enhanced installation flexibility;
4. Riveted enclosure structure securely connects stainless steel cylinder barrel with end covers;
5. Stainless steel piston rod and cylinder barrel enable operation in mildly corrosive environments;
6. Comprehensive selection of cylinder specifications and mounting accessories available.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MSI
AirTAC MSI Single-Acting Stainless Steel Mini Cylinder MSI10X10U Specifications
- Model: MSI10X10U
- Type: Single-acting (spring return)
- Bore size: 10mm
- Stroke: 10mm (±1mm)
- Operating pressure: 0.05–0.7 MPa
- Operating temperature: -10℃ to 100℃
- Port size: M5x0.8 (push-in fitting)
- Mounting style: Basic type (no flange)
- Cylinder material: SUS304 stainless steel
- Rod material: SUS304 stainless steel
- Seal material: Fluororubber (FKM)
- Cushion type: Elastic buffer
- Weight: 65g ±2g
- Dimensions (L×W×H):
- Retracted length: 60mm
- Extended length: 70mm
- Body diameter: 20mm
- Mounting hole spacing: 25mm (center-to-center)
Ultra-compact corrosion-resistant cylinder designed for precision motion in harsh environments. Features full stainless steel construction with medical-grade FKM seals, achieving 1,500km theoretical service life. Includes built-in auto-adjust cushioning for smooth operation up to 1,000 cycles/day. Requires 5μm filtered air and recommends ISO VG32 hydraulic oil lubrication for optimal performance.
- Cleanroom automation in semiconductor manufacturing
- Chemical dosing mechanisms in pharmaceutical equipment
- High-frequency sorting gates in food packaging lines
- Sterilization chamber door interlocks
- Precision lens positioning in optical inspection systems
Installation note:
Use stainless steel fasteners to prevent galvanic corrosion.
Maximum side load ≤1.5N. Lubricate through air port using oil-fog lubrication
(0.3-0.5mg/m³) when operating below -5℃.
| Property | Property Value |
|---|---|
| sku | MSI10X10U |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <10mm> |
