Airtac MSI Single Acting Stainless Steel Mini Cylinder MSI10X15SU
2. Front/rear covers with fixed cushion rings to minimize cylinder impact during directional changes;
3. Multiple rear cover configurations for enhanced installation flexibility;
4. Riveted enclosure structure securely connects stainless steel cylinder barrel with end covers;
5. Stainless steel piston rod and cylinder barrel enable operation in mildly corrosive environments;
6. Comprehensive selection of cylinder specifications and mounting accessories available.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MSI
AirTAC MSI Series Single-Acting Stainless Steel Mini Cylinder MSI10X15SU Specifications
- Model: MSI10X15SU
- Type: Single-Action (Spring Return)
- Bore Size: 10mm
- Stroke: 15mm
- Material: Stainless Steel (SUS304)
- Rod Material: Stainless Steel (SUS304)
- Seal Material: NBR (Nitrile Rubber)
- Operating Pressure: 0.15–0.8 MPa
- Operating Temperature: -20℃ to 150℃
- Cushioning: Adjustable Rubber Buffer
- Port Size: M5x0.8
- Weight: 180g ±5g
- Dimensions: 58mm(L) × 25mm(W) × 25mm(H)
- Protection Rating: IP67
- Mounting: Standard ISO 6432
- Double Bearing Structure: Yes
Ultra-compact corrosion-resistant cylinder with precision-ground stainless steel barrel and dual guide bearings for exceptional lateral load resistance. Features self-lubricating piston for maintenance-free operation in clean environments. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.4.2 air quality.
- Cleanroom automation in semiconductor manufacturing
- Precision positioning in medical device assembly
- Food packaging machinery (FDA-compliant version available)
- Laboratory analytical instrument actuation
- Pharmaceutical tablet press ejection systems
Installation note:
Use PTFE-based lubricant for high-temperature applications. Avoid side load exceeding 3N.
For vertical mounting, install with rod end downward to prevent debris accumulation.
Maximum piston speed: 500mm/s with cushion engaged.
| Property | Property Value |
|---|---|
| sku | MSI10X15SU |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <15mm> |
