Airtac MSI Single Acting Stainless Steel Mini Cylinder MSI10X20SCA
2. Front/rear covers with fixed cushion rings to minimize cylinder impact during directional changes;
3. Multiple rear cover configurations for enhanced installation flexibility;
4. Riveted enclosure structure securely connects stainless steel cylinder barrel with end covers;
5. Stainless steel piston rod and cylinder barrel enable operation in mildly corrosive environments;
6. Comprehensive selection of cylinder specifications and mounting accessories available.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MSI
AirTAC MSI Series Single-Acting Stainless Steel Mini Cylinder MSI10X20SCA Specifications
- Model: MSI10X20SCA
- Type: Single-acting (spring return)
- Bore size: 10mm
- Stroke: 20mm
- Material: Stainless steel (SUS304 body, CR-SUS piston rod)
- Operating pressure: 0.1–0.7 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (Rc1/8 adapter optional)
- Cushioning: Adjustable rubber buffer
- Seal material: NBR/FKM (optional)
- Mounting type: Basic (standard bracket)
- Weight: 150g ±5%
- Dimensions (L×W×H):
- Retracted length: 50mm
- Extended length: 70mm
- Body diameter: 20mm
- Mounting bracket: 34mm × 20mm
- Protection rating: IP65 (standard)
- Lubrication: Pre-lubricated (use ISO VG32 pneumatic oil)
Ultra-compact corrosion-resistant cylinder designed for precision motion control in confined spaces. Features laser-engraved identification marks and dual cushioning adjustment screws for smooth end-of-stroke deceleration. The stainless steel construction ensures compatibility with cleanroom environments and washdown applications.
- Medical device actuation systems
- Food processing equipment (FDA-compliant versions available)
- Semiconductor wafer handling robots
- Pharmaceutical tablet pressing mechanisms
- Precision optical component positioning
Installation guidelines:
Maximum lateral load ≤15N. For vertical mounting, maintain rod-end-down orientation.
Use filtered air (5μm+ filter) with dew point -25℃ below ambient. Cycle rate should not exceed 80% duty cycle at maximum stroke frequency.
| Property | Property Value |
|---|---|
| sku | MSI10X20SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <20mm> |
