Airtac MSI Single Acting Stainless Steel Mini Cylinder MSI10X20SU
2. Front/rear covers with fixed cushion rings to minimize cylinder impact during directional changes;
3. Multiple rear cover configurations for enhanced installation flexibility;
4. Riveted enclosure structure securely connects stainless steel cylinder barrel with end covers;
5. Stainless steel piston rod and cylinder barrel enable operation in mildly corrosive environments;
6. Comprehensive selection of cylinder specifications and mounting accessories available.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MSI
AirTAC MSI Series Single-Acting Stainless Steel Mini Cylinder MSI10X20SU Specifications
- Model: MSI10X20SU
- Type: Single-acting spring return (push type)
- Bore size: Ø10mm
- Stroke: 20mm (±1mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Ambient temperature: -10℃ to 80℃
- Port size: M5×0.8 (standard) with optional NPT1/8 adaptor
- Cushioning: Adjustable rubber bumper
- Body material: SUS304 stainless steel
- Rod material: SUS420J2 hardened stainless steel
- Seal material: Fluororubber (FKM) for high chemical resistance
- Weight: 98g ±2g (excluding accessories)
- Dimensions:
- Total length: 52mm (retracted)
- Extended length: 72mm
- Mounting base: 25mm(W) × 20mm(H)
- Rod thread: M4×0.7 external thread
- Protection rating: IP67 (standard wiper seal included)
- Lubrication: Pre-lubricated (maintenance-free operation)
Ultra-compact corrosion-resistant cylinder designed for precision linear motion in harsh environments. Features stainless-steel construction with FKM seals for chemical/steam resistance, making it ideal for cleanrooms and washdown applications. The integrated cushioning mechanism reduces impact noise while maintaining 500km+ service life at rated load.
- Pharmaceutical capsule filling machines
- Food packaging line actuators
- Semiconductor wafer handling robots
- Steam sterilization equipment
- Marine instrumentation controls
Installation tip:
Use 2x M4 mounting screws (max torque 1.2N·m). For vertical downward thrust applications,
reduce operating pressure by 20% to compensate for spring force. Always install air filter regulator (5μm+).
| Property | Property Value |
|---|---|
| sku | MSI10X20SU |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <20mm> |
