Airtac MSI Single Acting Stainless Steel Mini Cylinder MSI10X25CA
2. Front/rear covers with fixed cushion rings to minimize cylinder impact during directional changes;
3. Multiple rear cover configurations for enhanced installation flexibility;
4. Riveted enclosure structure securely connects stainless steel cylinder barrel with end covers;
5. Stainless steel piston rod and cylinder barrel enable operation in mildly corrosive environments;
6. Comprehensive selection of cylinder specifications and mounting accessories available.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MSI
AirTAC MSI Series Single-Acting Stainless Steel Mini Cylinder MSI10X25CA Specifications
- Model: MSI10X25CA
- Type: Single-acting spring return (stainless steel construction)
- Bore size: Ø10mm
- Stroke: 25mm
- Operating pressure: 0.15–0.8 MPa
- Port thread: M5×0.8 (dual ports standard)
- Cushioning: Adjustable rubber buffer
- Piston rod material: Stainless steel (SUS304)
- Seal material: NBR with grease retention design
- Ambient temperature: -20℃ to 80℃
- Weight: 0.22kg ±3%
- Dimensions (L×W×H):
- Retracted length: 80mm
- Extended length: 105mm
- Body width: 32mm
- Mounting base: 20×12mm
- ISO standard: 6432 (miniature cylinder specifications)
Corrosion-resistant mini cylinder featuring laser-etched position markers and dual anti-rotation guide slots. The electropolished surface (Ra≤0.8μm) prevents particulate shedding, with IP67-rated protection against washdown environments. Requires 5-40μm filtered air with ISO VG32 lubricant recommendation.
- Pharmaceutical tablet press ejection systems
- Semiconductor wafer handling robots
- Food packaging clip applicators
- Cleanroom conveyor diverters
- Precision optical lens positioning
Installation protocol:
Maintain ≤0.1mm/m alignment tolerance during mounting.
For vertical downward thrust applications, reduce operating pressure by 15%
to compensate for spring force. Lubricate through air supply at 1 drip/3m³.
| Property | Property Value |
|---|---|
| sku | MSI10X25CA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <25 mm> |
