Airtac MSI Single Acting Stainless Steel Mini Cylinder MSI10X25SU
2. Front/rear covers with fixed cushion rings to minimize cylinder impact during directional changes;
3. Multiple rear cover configurations for enhanced installation flexibility;
4. Riveted enclosure structure securely connects stainless steel cylinder barrel with end covers;
5. Stainless steel piston rod and cylinder barrel enable operation in mildly corrosive environments;
6. Comprehensive selection of cylinder specifications and mounting accessories available.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MSI
AirTAC MSI Single-Acting Stainless Steel Mini Cylinder MSI10X25SU
- Model: MSI10X25SU
- Type: Single-acting spring return
- Bore size: 10mm
- Stroke: 25mm
- Material: SUS304 stainless steel (body & rod)
- Operating pressure: 0.05–0.7 MPa
- Temperature range: -20℃ to 150℃
- Port size: M5x0.8 (standard), optional NPT1/8
- Cushioning: Adjustable rubber bumper
- Mounting style: Basic rod-type (optional foot/block mounts)
- Seal material: Fluororubber (FKM)
- Corrosion resistance: IP67 (standard), IP69K optional
- Weight: 0.23 kg
- Dimensions:
- Length: 105mm (fully extended)
- Width: 24mm (body diameter)
- Height: 28mm (mounting base to rod center)
Ultra-compact corrosion-resistant cylinder designed for precision linear motion in harsh environments. Features medical-grade surface finish (Ra≤0.8μm) and chemical-resistant seals. Requires 5μm filtered air with ISO 8573-1:2010 Class 3 air quality. Optional auto switch models (MSI10X25SU-M9BW) available for position feedback.
- Cleanroom automation in semiconductor manufacturing
- Food processing machinery (FDA-compliant version)
- Medical device actuation systems
- Marine equipment controls
- High-temperature sterilization chambers
Installation note:
Lubricate with ISO VG32 turbine oil before initial use. For vertical mounting,
maintain minimum 2mm clearance below cylinder for condensate drainage.
Maximum side load: 3N at rod end.
| Property | Property Value |
|---|---|
| sku | MSI10X25SU |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <25 mm> |
