Airtac MSI Single Acting Stainless Steel Mini Cylinder MSI10X25U
2. Front/rear covers with fixed cushion rings to minimize cylinder impact during directional changes;
3. Multiple rear cover configurations for enhanced installation flexibility;
4. Riveted enclosure structure securely connects stainless steel cylinder barrel with end covers;
5. Stainless steel piston rod and cylinder barrel enable operation in mildly corrosive environments;
6. Comprehensive selection of cylinder specifications and mounting accessories available.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MSI
AirTAC MSI Series Single-Acting Stainless Steel Mini Cylinder MSI10X25U
- Model: MSI10X25U
- Type: Single-acting spring return
- Bore size: 10mm (0.39")
- Stroke: 25mm (0.98")
- Operation: Air pressure extension / Spring retraction
- Material: Stainless steel cylinder tube, CR20Mo piston rod
- Operating pressure range: 0.15–0.8 MPa (21.7–116 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Port size: M5x0.8 (standard) with NPT1/8 adapter option
- Cushioning: Adjustable rubber bumper
- Mounting style: Basic non-magnetic base with 2x M3 threaded holes
- Weight: 0.12kg (4.23oz)
- Dimensions: 80mm(L) × 20mm(W) × 20mm(H) (3.15" × 0.79" × 0.79")
- Rod thread: M4x0.7 external thread at piston end
- Seal material: High-grade NBR with stainless steel wear band
- Corrosion resistance: IP67 equivalent (non-certified)
Ultra-compact stainless steel cylinder designed for corrosive environments and precision motion control. Features non-magnetic construction with chromium-plated piston rod for smooth operation. Ideal for applications requiring frequent sterilization or exposure to chemicals. Requires filtered air (5-50μm) with lubrication optional.
- Pharmaceutical tablet pressing machines
- Food packaging equipment (FDA-compliant environments)
- Semiconductor wafer handling systems
- Medical device actuation mechanisms
- Cleanroom automation components
- Marine instrumentation controls
Installation guidelines:
Mount using M3 screws with 4.8N·m torque max. Allow 1mm clearance for thermal expansion.
Lubricate with ISO VG32 hydraulic oil if used in dry air systems. Avoid side loads exceeding 2N.
| Property | Property Value |
|---|---|
| sku | MSI10X25U |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <25 mm> |
