Airtac MSI Single Acting Stainless Steel Mini Cylinder MSI10X30CA
2. Front/rear covers with fixed cushion rings to minimize cylinder impact during directional changes;
3. Multiple rear cover configurations for enhanced installation flexibility;
4. Riveted enclosure structure securely connects stainless steel cylinder barrel with end covers;
5. Stainless steel piston rod and cylinder barrel enable operation in mildly corrosive environments;
6. Comprehensive selection of cylinder specifications and mounting accessories available.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MSI
AirTAC MSI Series Single-Acting Stainless Steel Mini Cylinder MSI10X30CA Specifications
- Model: MSI10X30CA
- Type: Single-acting (spring return)
- Bore size: 10mm
- Stroke: 30mm
- Material: SUS304 stainless steel body
- Operating pressure: 0.15–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Rubber buffer
- Port size: M5x0.8
- Seal material: NBR (Nitrile), optional FKM available
- Piston speed: 50–800 mm/s
- Mounting type: Square flange (MF1)
- Weight: 0.12 kg
- Dimensions (L×W×H): 70mm × 20mm × 50mm
- Rod thread: M5x0.8 external thread
- ISO certification: 6431, VDMA 24562
- Protection rating: IP67 (dust/water resistant)
Ultra-compact corrosion-resistant cylinder optimized for precision motion in confined spaces. Features precision-ground stainless steel barrel and chromium-plated piston rod for exceptional durability in humid or chemically aggressive environments. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3 air quality.
- Cleanroom automation in semiconductor manufacturing
- Precision dosing mechanisms in food packaging
- Medical sterilization equipment actuators
- Marine environment control systems
- Pharmaceutical tablet pressing machines
Installation guidelines:
Lubricate with ISO VG32 hydraulic oil before initial use.
For vertical mounting, position rod end downward to prevent
particle accumulation. Max lateral load: 2.5N.
Allow 5mm clearance for rod extension during maintenance.
| Property | Property Value |
|---|---|
| sku | MSI10X30CA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | 30mm |
