Airtac MSI Single Acting Stainless Steel Mini Cylinder MSI10X30SU
2. Front/rear covers with fixed cushion rings to minimize cylinder impact during directional changes;
3. Multiple rear cover configurations for enhanced installation flexibility;
4. Riveted enclosure structure securely connects stainless steel cylinder barrel with end covers;
5. Stainless steel piston rod and cylinder barrel enable operation in mildly corrosive environments;
6. Comprehensive selection of cylinder specifications and mounting accessories available.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MSI
AirTAC MSI10X30SU Single-Acting Stainless Steel Mini Cylinder Specifications
- Model: MSI10X30SU
- Type: Single-acting (spring return)
- Bore size: Ø10mm
- Stroke: 30mm (±1mm)
- Material: Stainless steel body & piston rod
- Seal material: NBR/FKM (optional fluorocarbon)
- Operating pressure: 0.15–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Rubber bumper
- Port size: M5×0.8 (UNF 10-32 optional)
- Weight: 0.15kg (excludes accessories)
- Dimensions:
- Body diameter: Ø32mm
- Total length: 70mm (at full retraction)
- Mounting base: 20×20mm square profile
- Rod thread: M5×0.8 external
- Lubrication: Pre-lubricated (Grease-free operation)
- ISO standard: 6432 compliant
Ultra-compact corrosion-resistant cylinder featuring precision-ground stainless steel construction for hygienic environments. The spring-return mechanism provides 4.1N return force (at 0.5MPa) with ≤0.5mm position repeatability. Optional magnetic piston version (MSI10X30SU-M) available for position sensing.
- Cleanroom medical device actuators
- Semiconductor wafer handling systems
- Food processing equipment (NSF compliant)
- High-cycle laboratory automation (50+ million cycles rating)
- Coastal robotics (saltwater resistant)
Installation tip:
Use 2x M4 screws (max 0.7Nm torque) for base mounting.
For vertical downward thrust applications, maintain ≥0.3MPa pressure
to overcome spring force. Lubricate rod with silicone grease (PM600S)
monthly in high-cycle use.
| Property | Property Value |
|---|---|
| sku | MSI10X30SU |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | 30mm |
