Airtac MSI Single Acting Stainless Steel Mini Cylinder MSI10X40CA
$19.76
Regular price
$27.26
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MSI10X40CA
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with ISO 6432 standard (φ8~25);
2. Front/rear covers with fixed cushion rings to minimize cylinder impact during directional changes;
3. Multiple rear cover configurations for enhanced installation flexibility;
4. Riveted enclosure structure securely connects stainless steel cylinder barrel with end covers;
5. Stainless steel piston rod and cylinder barrel enable operation in mildly corrosive environments;
6. Comprehensive selection of cylinder specifications and mounting accessories available.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MSI
Installation notes:
Maintain 0.5-1mm alignment tolerance during mounting. Use stainless steel fasteners only.
Lubricate every 500,000 cycles with silicone-free grease (ISO VG32 equivalent).
For vertical mounting, install with rod end downward to prevent moisture accumulation.
2. Front/rear covers with fixed cushion rings to minimize cylinder impact during directional changes;
3. Multiple rear cover configurations for enhanced installation flexibility;
4. Riveted enclosure structure securely connects stainless steel cylinder barrel with end covers;
5. Stainless steel piston rod and cylinder barrel enable operation in mildly corrosive environments;
6. Comprehensive selection of cylinder specifications and mounting accessories available.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MSI
AirTAC MSI Series Single-Acting Stainless Steel Mini Cylinder MSI10X40CA Specifications
- Model: MSI10X40CA
- Type: Single-acting (spring return)
- Bore size: Ø10mm
- Stroke: 40mm (±0.5mm tolerance)
- Material: SUS304 stainless steel body
- Rod material: SUS304 + hard chrome plating (3μm)
- Seal material: Fluororubber (FKM) + NBR
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 150℃
- Cushioning: Adjustable rubber bumper
- Port size: M5×0.8 (standard) with NPT1/8 adapter option
- Weight: 0.32kg (including fittings)
- Dimensions: 120mm(L) × 30mm(W) × 30mm(H)
- Protection rating: IP67 (standard), IP69K optional
- Lubrication: Pre-lubricated (Grease G-46)
Corrosion-resistant mini cylinder with ultra-compact design, featuring dual-material seals for high/low temperature resistance. Precision-ground rod ensures smooth operation in cleanroom environments. The 304 stainless construction prevents rust in washdown applications.
Ideal Applications:
- Pharmaceutical production line actuators
- Food packaging machinery (FDA-compliant)
- Semiconductor wafer handling robots
- Marine equipment controls
- Sterilization chamber mechanisms
Installation notes:
Maintain 0.5-1mm alignment tolerance during mounting. Use stainless steel fasteners only.
Lubricate every 500,000 cycles with silicone-free grease (ISO VG32 equivalent).
For vertical mounting, install with rod end downward to prevent moisture accumulation.
WARNING:
Requires 40μm filtered air supply. Avoid rapid pressure changes >0.3 MPa/sec.
Maximum side load: 5N. Do not disassemble cushioning mechanism without factory tooling.
| Property | Property Value |
|---|---|
| sku | MSI10X40CA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <40mm> |
