Airtac MSI Single Acting Stainless Steel Mini Cylinder MSI10X40U
2. Front/rear covers with fixed cushion rings to minimize cylinder impact during directional changes;
3. Multiple rear cover configurations for enhanced installation flexibility;
4. Riveted enclosure structure securely connects stainless steel cylinder barrel with end covers;
5. Stainless steel piston rod and cylinder barrel enable operation in mildly corrosive environments;
6. Comprehensive selection of cylinder specifications and mounting accessories available.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MSI
AirTAC MSI10X40U Single-Acting Stainless Steel Mini Cylinder Specifications
- Model: MSI10X40U
- Type: Single-acting (spring return)
- Bore size: 10mm
- Stroke: 40mm
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 150℃
- Port thread: M5×0.8 (standard) / NPT1/8 (optional)
- Cushioning: Adjustable rubber buffer
- Material: Stainless steel (SUS304 barrel, CRMo alloy piston rod)
- Seal material: Fluororubber (FKM) for high temp resistance
- Weight: 210g ±5g
- Dimensions:
- Body length: 85mm (excluding rod)
- Total extended length: 125mm (stroke included)
- Mounting base: 20mm(W) × 20mm(H)
- Rod end thread: M6×1.0
- Protection rating: IP67 (dust/water resistant)
- Lubrication: Pre-lubricated (maintenance-free for 3000km stroke)
Ultra-compact stainless steel cylinder with corrosion-resistant construction, designed for harsh environments requiring precise linear motion. Features a spring-return mechanism with 3-position mounting holes (front flange, rear threaded, side tapped). The hardened piston rod (HRC 35-40) ensures wear resistance in high-cycle applications.
- Semiconductor wafer handling robots
- Food packaging machinery (FDA-compliant)
- Pharmaceutical tablet press ejection systems
- High-temperature oven door actuators
- Marine equipment controls
Installation note:
For optimal performance, maintain ≤0.5mm alignment tolerance during mounting.
Use clean dry air (ISO 8573-1:2010 Class 2-4-2) and install an inline filter
when used in particle-sensitive applications. Lubricate with ISO VG32 turbine oil
if operating below -10℃.
| Property | Property Value |
|---|---|
| sku | MSI10X40U |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <40mm> |
