Airtac MSI Single Acting Stainless Steel Mini Cylinder MSI10X45SU
2. Front/rear covers with fixed cushion rings to minimize cylinder impact during directional changes;
3. Multiple rear cover configurations for enhanced installation flexibility;
4. Riveted enclosure structure securely connects stainless steel cylinder barrel with end covers;
5. Stainless steel piston rod and cylinder barrel enable operation in mildly corrosive environments;
6. Comprehensive selection of cylinder specifications and mounting accessories available.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MSI
AirTAC MSI Single-Acting Stainless Steel Mini Cylinder MSI10X45SU Specifications
- Model: MSI10X45SU
- Type: Single-acting (spring return) stainless steel cylinder
- Bore size: 10mm
- Stroke: 45mm
- Material: SUS304 stainless steel (body & piston rod)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Rubber buffer (adjustable at one end)
- Port size: M5x0.8 (standard) or PT1/8 optional
- Mounting options: Basic type (no pre-mounting accessories)
- Weight: 0.25kg ±5%
- Dimensions: 85mm(L) × 20mm(W) × 20mm(H) (extended length)
- Rod thread: M5x0.8 female thread
- Lubrication: Pre-lubricated (dry cycle compatible)
- ISO standard: 6432 compliant (compact series)
Ultra-compact corrosion-resistant cylinder designed for precision linear motion in confined spaces. Features full stainless steel construction for chemical resistance and washdown environments. The spring-return mechanism ensures fail-safe retraction with ≤0.6N residual spring force at maximum extension. Requires 5μm filtered air with <40% relative oil content.
- Pharmaceutical capsule filling machines
- Semiconductor wafer handling systems
- Food packaging line actuators
- Laboratory liquid dispensing systems
- Cleanroom automation equipment
Installation note:
Maintain 0.5-1mm alignment tolerance during mounting. For vertical installations,
use rod-end down orientation to prevent condensation accumulation.
Cycle rate should not exceed 120cpm without additional cushioning.
| Property | Property Value |
|---|---|
| sku | MSI10X45SU |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <45mm> |
