Airtac MSI Single Acting Stainless Steel Mini Cylinder MSI10X50SU
2. Front/rear covers with fixed cushion rings to minimize cylinder impact during directional changes;
3. Multiple rear cover configurations for enhanced installation flexibility;
4. Riveted enclosure structure securely connects stainless steel cylinder barrel with end covers;
5. Stainless steel piston rod and cylinder barrel enable operation in mildly corrosive environments;
6. Comprehensive selection of cylinder specifications and mounting accessories available.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MSI
AirTAC MSI Series Single-Acting Stainless Steel Mini Cylinder MSI10X50SU
- Model: MSI10X50SU
- Type: Single-acting (spring return)
- Bore size: 10mm
- Stroke: 50mm (±0.5mm tolerance)
- Material: SUS304 stainless steel body
- Rod material: SUS303 stainless steel
- Seal type: Fluororubber (FKM) for high temperature resistance
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 150℃
- Cushioning: Adjustable rubber bumper
- Port size: M5x0.8 (standard)
- Lubrication: Pre-lubricated (maintenance-free design)
- Weight: 0.23kg
- Dimensions:
- Length: 119mm (fully extended)
- Width: 28mm (mounting bracket included)
- Height: 28mm (square body profile)
- ISO standard: Compliant with ISO 6432 mini cylinder specifications
Ultra-compact corrosion-resistant cylinder designed for harsh environments requiring frequent sterilization or chemical exposure. Features precision-ground rod and dual sealing system (rod seal + piston seal) for leak-free operation. The stainless steel construction prevents rust formation in high-humidity conditions, while FKM seals maintain flexibility across extreme temperatures.
- Pharmaceutical packaging machinery
- Food processing automation lines
- Semiconductor wafer handling systems
- Laboratory analytical instruments
- Marine equipment actuators
- Cleanroom manufacturing processes
Installation tips:
Use compatible stainless steel fittings to prevent galvanic corrosion.
For vertical mounting, ensure spring chamber orientation faces downward
to prevent debris accumulation. Maximum side load: 3N at full extension.
| Property | Property Value |
|---|---|
| sku | MSI10X50SU |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <50mm> |
