Airtac MSI Single Acting Stainless Steel Mini Cylinder MSI10X50U
2. Front/rear covers with fixed cushion rings to minimize cylinder impact during directional changes;
3. Multiple rear cover configurations for enhanced installation flexibility;
4. Riveted enclosure structure securely connects stainless steel cylinder barrel with end covers;
5. Stainless steel piston rod and cylinder barrel enable operation in mildly corrosive environments;
6. Comprehensive selection of cylinder specifications and mounting accessories available.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MSI
AirTAC MSI Series Single-Acting Stainless Steel Mini Cylinder MSI10X50U
- Model: MSI10X50U
- Type: Single-acting spring return (push type)
- Bore size: 10mm
- Stroke: 50mm (±1mm tolerance)
- Material: Stainless steel (SUS304 barrel/piston rod)
- Seal material: NBR/FKM (optional fluorocarbon seals)
- Operating pressure: 0.15–0.7 MPa
- Operating temperature: -20℃ to 80℃ (NBR) / -10℃ to 150℃ (FKM)
- Cushion type: Adjustable buffer (both ends)
- Port size: M5x0.8 (standard) or 1/8 NPT optional
- Rod thread: M5x0.8 external thread
- Weight: 165g ±3% (without accessories)
- Dimensions:
- Length (retracted): 98mm
- Body diameter: Φ20mm
- Stroke tolerance: +1.0mm/-0.0mm
- Mounting bracket spacing: 25mm center-to-center
- Lubrication: Pre-lubricated (Grease-free operation)
- Protection rating: IP65 (standard wiper design)
- Cycle rate: ≤5 cycles/second (with cushioning)
Ultra-compact stainless steel cylinder engineered for corrosive environments and space-constrained automation. Features precision-ground rod with chrome plating (3-5μm thickness) for wear resistance. The double-sealed piston design ensures leak-free operation even under side load conditions. Requires filtered air (≤40μm particles) with recommended ISO VG32 hydraulic oil mist lubrication.
- Pharmaceutical tablet pressing machines
- Semiconductor wafer handling robots
- Food packaging line actuators
- Micro-positioning in optical equipment
- Cleanroom automation systems
- Dental CNC milling machines
Maintenance Tip:
Perform monthly rod seal inspections in high-cycle applications (>500k cycles/year).
Use only neutral detergents for cleaning - acidic solutions may damage stainless surface passivation layer.
| Property | Property Value |
|---|---|
| sku | MSI10X50U |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <50mm> |
