Airtac MSU Mini Free Mounting Cylinder MSU10X8
2. Features four-way mounting capability for flexible installation;
3. Space-efficient design allows multiple cylinders to be grouped in parallel configurations;
4. Integrated front guiding boss ensures precise alignment and reliable positioning;
5. Precision-honed bore with hard anodized treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic version enables position sensing functionality;
7. Pre-machined T-slots on barrel facilitate versatile magnetic sensor mounting;
8. Asymmetrical bidirectional piston sealing system with compact dimensions and integrated oil reservoir design.
Category: Free Mount Cylinder | Brand: AIRTAC | Series: MSU
AirTAC MSU Miniature Free Mount Cylinder MSU10X8 Technical Specifications
- Model Series: MSU10X8 (Standard Stroke 8mm)
- Bore Size: Ø10mm (±0.1mm tolerance)
- Stroke: 8mm (Customizable 1-30mm)
- Operating Pressure: 0.05-0.9 MPa
- Cushioning: Adjustable rubber bumper (both ends)
- Port Size: M5x0.8 (Standard) / NPT1/8 (Optional)
- Ambient Temperature: -20℃ to +80℃
- Piston Speed: 50-800 mm/s (Lubricated condition)
- Material:
- Cylinder Tube: Hard anodized aluminum alloy
- Piston Rod: Stainless steel SUS304
- Seals: Heat-resistant NBR (Nitrile)
- Weight: 0.15kg (Without accessories)
- Dimensions:
- Body Length: 58mm (Stroke 8mm version)
- Mounting Width: 18mm (Compact flange)
- Overall Height: 22mm (Including rod)
- Rod Thread: M4x0.7 (External)
Ultra-compact cylinder featuring a space-saving design with 360° free mounting capability through 4xM3 threaded holes. Precision-ground rod and double O-ring design ensures ≤0.05mm repeat positioning accuracy. Optional magnetic piston version (MSU10X8-M) enables position feedback. Lubrication-free operation with built-in wear-resistant guide bushings.
- PCB handling robots in electronics assembly
- Precision clamping in optical lens production
- Valve actuation in portable medical analyzers
- Sorting mechanisms in micro-part conveyors
- Automated test equipment probe positioning
Installation Tips:
Maintain 0.5-1mm clearance between rod end and load during alignment.
For vertical mounting, use counterbalance valves when handling >0.3kg loads.
Apply Loctite 243 on mounting screws (torque ≤1.2N·m).
| Property | Property Value |
|---|---|
| sku | MSU10X8 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <8mm> |
