Airtac MSU Mini Free Mounting Cylinder MSU12X10
$25.81
Regular price
$33.31
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MSU12X10
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS (Japanese Industrial Standards) specifications;
2. Features four-way mounting capability for flexible installation;
3. Space-efficient design allows multiple cylinders to be grouped in parallel configurations;
4. Integrated front guiding boss ensures precise alignment and reliable positioning;
5. Precision-honed bore with hard anodized treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic version enables position sensing functionality;
7. Pre-machined T-slots on barrel facilitate versatile magnetic sensor mounting;
8. Asymmetrical bidirectional piston sealing system with compact dimensions and integrated oil reservoir design.
Category: Free Mount Cylinder | Brand: AIRTAC | Series: MSU
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use. Maintain 0.3mm minimum clearance between magnetic sensor and cylinder body. For vertical mounting, use counterbalance valves when handling suspended loads over 2kg.
2. Features four-way mounting capability for flexible installation;
3. Space-efficient design allows multiple cylinders to be grouped in parallel configurations;
4. Integrated front guiding boss ensures precise alignment and reliable positioning;
5. Precision-honed bore with hard anodized treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic version enables position sensing functionality;
7. Pre-machined T-slots on barrel facilitate versatile magnetic sensor mounting;
8. Asymmetrical bidirectional piston sealing system with compact dimensions and integrated oil reservoir design.
Category: Free Mount Cylinder | Brand: AIRTAC | Series: MSU
AirTAC MSU12X10 Compact Free Mount Cylinder Specifications
- Model: MSU12X10
- Type: Double-acting compact cylinder
- Bore size: 12mm
- Stroke: 10mm (Standard), customizable up to 100mm
- Operating pressure: 0.05–1.0 MPa (7-145 psi)
- Cushioning: Adjustable rubber buffer
- Mounting style: Free installation (no specific mounting orientation required)
- Port size: M5x0.8 threaded
- Temperature range: -20℃ to 80℃ (operating), -30℃ to 90℃ (storage)
- Material:
- Barrel: Aluminum alloy with hard anodizing
- Piston rod: Stainless steel (SUS304)
- End caps: Die-cast aluminum
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP54
- Weight: 0.28kg (with standard accessories)
- Dimensions:
- Total length: 100mm (at mid-stroke)
- Body width: 20mm
- Height with mounting: 34mm
Ultra-compact cylinder featuring space-saving design with 40% reduced installation area compared to standard models. The through-hole piston rod structure enables multi-directional force transmission, ideal for precision positioning in confined spaces. Includes built-in magnet for position sensing compatibility.
Typical Applications:
- Medical device actuation systems
- Semiconductor handling robots
- Desktop CNC machine tool clamps
- 3D printer automated tool changers
- Laboratory sample positioning stages
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use. Maintain 0.3mm minimum clearance between magnetic sensor and cylinder body. For vertical mounting, use counterbalance valves when handling suspended loads over 2kg.
Maintenance:
- Re-lubrication interval: 3 million cycles or 12 months
- Max side load: 5N at full extension
- Recommended air quality: 40μm filtered, dew point -20℃ below ambient
| Property | Property Value |
|---|---|
| sku | MSU12X10 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
