Airtac MSU Mini Free Mounting Cylinder MSU12X5
2. Features four-way mounting capability for flexible installation;
3. Space-efficient design allows multiple cylinders to be grouped in parallel configurations;
4. Integrated front guiding boss ensures precise alignment and reliable positioning;
5. Precision-honed bore with hard anodized treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic version enables position sensing functionality;
7. Pre-machined T-slots on barrel facilitate versatile magnetic sensor mounting;
8. Asymmetrical bidirectional piston sealing system with compact dimensions and integrated oil reservoir design.
Category: Free Mount Cylinder | Brand: AIRTAC | Series: MSU
AirTAC MSU Series Miniature Free Mount Cylinder MSU12X5 Technical Details
- Model: MSU12X5
- Type: Single-acting spring return cylinder (Push type)
- Bore size: 12mm
- Stroke: 5mm (Customizable 1-50mm)
- Operating pressure: 0.15-0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Rubber buffer (adjustable end caps)
- Port size: M5x0.8
- Piston speed: 50-700 mm/s
- Mounting style: Non-rotating rod with 2x M3 threaded mounting holes
- Rod material: Stainless steel SUS304
- Tube material: Anodized aluminum alloy
- Seal type: NBR seals (Fluorocarbon optional)
- Weight: 0.068 kg
- Dimensions: 62mm(L) × 20mm(W) × 20mm(H)
- Protection class: IP54 (standard), IP67 (optional with special seals)
Ultra-compact pneumatic cylinder featuring space-saving cube-shaped design with integrated mounting points. The MSU12X5's anti-rotation mechanism ensures precise linear motion, while its corrosion-resistant construction withstands harsh industrial environments. Requires 5μm filtered air and monthly lubrication for optimal performance.
- PCB handling robots in electronics assembly
- Precision valve actuation in analytical instruments
- Paper feed mechanisms in compact printers
- Medical device positioning systems
- Automated test equipment jigs
Installation note:
Compatible with horizontal/vertical mounting. Apply Loctite 243 to mounting screws (0.6-1.0 N·m torque).
Lubricate every 500km of stroke travel using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | MSU12X5 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <5mm> |
