Airtac MSUR Compact Free Mounting Cylinder MSUR12X10B
2. Features four-directional mounting capability for flexible installation;
3. Space-saving gang-mounting design allows multiple cylinder combination;
4. Integrated guide boss ensures precise positioning alignment;
5. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and longevity;
6. Optional magnetic piston version enables position detection functionality;
7. Pre-machined T-slots on cylinder body facilitate adjustable sensor switch mounting;
8. Patented asymmetrical bidirectional sealing structure with compact profile and integrated lubrication reservoir.
Category: Compact Body Cylinder , Brand: AirTAC , Series: MSUR
AirTAC MSUR Compact Free Mount Cylinder MSUR12X10B Technical Details
- Model Code: MSUR12X10B
- Bore Size: 12mm
- Stroke: 10mm (customizable 1-30mm)
- Operating Pressure: 0.05-0.9 MPa
- Medium: Clean dry air (lubricated or non-lubricated)
- Ambient Temperature: -20℃ to 80℃
- Piston Speed: 50-700 mm/s
- Cushioning: Elastic rubber buffer + adjustable cushion screw
- Mounting Types: Free position (no bracket) with optional front flange (MFH) or rear flange (MFQ)
- Port Size: M5x0.8 (standard) with NPT1/8 adapter available
- Body Material: Aluminum alloy (anodized)
- Rod Material: Stainless steel (SUS304)
- Seal Material: Polyurethane (NBR optional)
- Weight: 98g ±2%
- Dimensions:
- Length: 61mm (including rod)
- Width: 24mm (cylinder body diameter)
- Height: 24mm (cylinder body diameter)
Ultra-compact pneumatic cylinder designed for space-constrained automation systems. Features dual cushioning system for smooth end-stroke deceleration and maintenance-free operation. The rod end includes a 4mm threaded hole (M3x0.5) for flexible accessory mounting. Compatible with magnetic sensors for position detection (sensor groove pre-machined).
- PCB handling robots in electronics manufacturing
- Precision valve actuation in medical devices
- Miniature clamping mechanisms in watchmaking
- Paper feed systems in compact printers
- Laboratory sample positioning stages
Installation Guidelines:
Maximum side load capacity 2.5N. For vertical mounting,
use speed controller (ASC-06) to prevent piston rod buckling.
Lubricate with ISO VG32 turbine oil if using non-lubricated air supply.
| Property | Property Value |
|---|---|
| sku | MSUR12X10B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
