Airtac MSUR Compact Free Mounting Cylinder MSUR12X10SB
2. Features four-directional mounting capability for flexible installation;
3. Space-saving gang-mounting design allows multiple cylinder combination;
4. Integrated guide boss ensures precise positioning alignment;
5. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and longevity;
6. Optional magnetic piston version enables position detection functionality;
7. Pre-machined T-slots on cylinder body facilitate adjustable sensor switch mounting;
8. Patented asymmetrical bidirectional sealing structure with compact profile and integrated lubrication reservoir.
Category: Compact Body Cylinder , Brand: AirTAC , Series: MSUR
AirTAC MSUR Series Compact Cylinder MSUR12X10SB Technical Details
- Model: MSUR12X10SB
- Bore size: 12mm (0.47")
- Stroke: 10mm (0.39")
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-700 mm/s
- Port size: M5x0.8 (dual ports)
- Cushioning: Adjustable rubber buffer
- Mounting type: Free installation (no specific mounting bracket)
- Rod material: Hard chrome-plated steel
- Cylinder tube: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 0.12kg (0.26lbs)
- Dimensions:
- Total length: 58mm (2.28")
- Body diameter: Φ20mm (0.79")
- Rod end thread: M4x0.7
- Protection rating: IP40 (standard dust protection)
- Lubrication: Pre-lubricated (maintenance-free operation)
Ultra-compact cylinder designed for space-constrained automation systems, featuring a streamlined aluminum body with corrosion-resistant surface treatment. The dual-port design allows flexible piping configurations, while the chrome-plated piston rod ensures smooth operation and extended service life. Includes built-in auto-switch mounting slots for sensor integration.
- PCB handling robots in electronics manufacturing
- Precision dosing mechanisms in medical devices
- Semiconductor wafer positioning systems
- Compact clamping fixtures for CNC machines
- Automated test equipment actuator components
Installation guidelines:
Ensure proper rod alignment (max 0.2mm lateral offset tolerance).
Use backup nuts on rod threads when attaching accessories.
For vertical mounting, consider adding an external guide mechanism
for stability during high-speed operations.
| Property | Property Value |
|---|---|
| sku | MSUR12X10SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
