Airtac MSUR Compact Free Mounting Cylinder MSUR12X5
2. Features four-directional mounting capability for flexible installation;
3. Space-saving gang-mounting design allows multiple cylinder combination;
4. Integrated guide boss ensures precise positioning alignment;
5. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and longevity;
6. Optional magnetic piston version enables position detection functionality;
7. Pre-machined T-slots on cylinder body facilitate adjustable sensor switch mounting;
8. Patented asymmetrical bidirectional sealing structure with compact profile and integrated lubrication reservoir.
Category: Compact Body Cylinder , Brand: AirTAC , Series: MSUR
AirTAC MSUR12X5 Compact Free Mount Cylinder Specifications
- Series: MSUR (Miniature Free Mount Cylinder)
- Bore size: 12mm (0.47")
- Stroke: 50mm (1.97") standard (customizable 5-100mm)
- Operating pressure: 0.05-1.0 MPa (7-145 PSI)
- Operating temperature: -10℃ to 70℃ (14°F to 158°F)
- Cushioning: Rubber bumper + adjustable air cushion
- Port size: M5x0.8 (dual ports on both ends)
- Piston rod thread: M5x0.8 (male thread)
- Material: Aluminum barrel, CRMo steel rod
- Seal type: NBR seals (optional FKM for high temp)
- Weight: 145g ±3% (bare cylinder without accessories)
- Dimensions: 72mm(L) × 34mm(W) × 34mm(H) (at mid-stroke position)
- Max speed: 500mm/s (with cushioning)
- Mounting: Non-rotating rod with 4x M3 threaded holes (8mm spacing)
- ISO standard: 6432 compliant
Ultra-compact cylinder featuring space-saving cube-shaped design with through-hole mounting capability. Precision-machined guide grooves prevent piston rotation (≤0.5° deviation). Integrated shock absorption combines rubber buffers and tunable pneumatic cushioning. Optional magnetic piston version (MSUR12X5-M) for position sensing.
- PCB handling robots - component insertion
- Pharmaceutical blister packaging machines
- Semiconductor wafer clamping mechanisms
- 3D printer automatic bed leveling systems
- Textile machinery thread tension control
Installation tip:
Use precision alignment jig (AIRTAC PN: AMT-12F) during mounting to maintain ≤0.1mm parallelism.
Lubricate with ISO VG32 hydraulic oil if operating below -5℃. Avoid side load exceeding 3N.
| Property | Property Value |
|---|---|
| sku | MSUR12X5 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <5mm> |
