Airtac MSUR Compact Free Mounting Cylinder MSUR12X5B
2. Features four-directional mounting capability for flexible installation;
3. Space-saving gang-mounting design allows multiple cylinder combination;
4. Integrated guide boss ensures precise positioning alignment;
5. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and longevity;
6. Optional magnetic piston version enables position detection functionality;
7. Pre-machined T-slots on cylinder body facilitate adjustable sensor switch mounting;
8. Patented asymmetrical bidirectional sealing structure with compact profile and integrated lubrication reservoir.
Category: Compact Body Cylinder , Brand: AirTAC , Series: MSUR
AirTAC MSUR12X5B Compact Free Mount Cylinder Specifications
- Model: MSUR12X5B
- Type: Double-acting, free mount miniature cylinder
- Bore size: 12mm (0.47")
- Stroke: 5mm (0.2")
- Operating pressure: 0.05–0.9 MPa (7–130 psi)
- Cushion type: Fixed rubber bumper
- Mounting style: No dedicated mount – direct installation via through holes
- Port size: M5 (Rc1/8/NPT1/8 optional)
- Temperature range: -10℃ to 70℃ (14°F to 158°F)
- Seal material: NBR (Nitrile rubber)
- Weight: 0.15kg (0.33lb)
- Dimensions:
- Length: 43mm (1.69") [Cylinder body only]
- Width: 16mm (0.63") [Port to port]
- Height: 12mm (0.47") [Bore diameter]
- Mounting hole spacing: 25mm (0.98") center-to-center
- Max piston speed: 500mm/s
- Lubrication: Pre-lubricated (Maintenance-free)
- Protection rating: IP40 (Dust protected)
Ultra-compact pneumatic cylinder designed for space-constrained automation applications. Features a unique "clamp-free" installation system with 4xM3 through holes for direct mounting. The anodized aluminum construction ensures corrosion resistance while maintaining lightweight properties. Includes built-in magnetic ring for sensor compatibility (inductive sensors sold separately).
- Precision positioning in SMT component placement machines
- Medical device actuation (e.g., fluid control valves)
- Compact gripper mechanisms in collaborative robots
- Paper feed mechanisms in office automation equipment
- Valve switching in analytical instruments
Installation note:
Use class 4.8 or higher screws for mounting. Avoid side load exceeding 2N.
For optimal performance, maintain air filtration at 40μm or finer. Allow 0.5mm
clearance around cylinder during installation for thermal expansion.
| Property | Property Value |
|---|---|
| sku | MSUR12X5B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <5mm> |
