Airtac MSUR Compact Free Mounting Cylinder MSUR12X5SB
2. Features four-directional mounting capability for flexible installation;
3. Space-saving gang-mounting design allows multiple cylinder combination;
4. Integrated guide boss ensures precise positioning alignment;
5. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and longevity;
6. Optional magnetic piston version enables position detection functionality;
7. Pre-machined T-slots on cylinder body facilitate adjustable sensor switch mounting;
8. Patented asymmetrical bidirectional sealing structure with compact profile and integrated lubrication reservoir.
Category: Compact Body Cylinder , Brand: AirTAC , Series: MSUR
AirTAC MSUR12X5SB Compact Free Mount Cylinder Specifications
- Model: MSUR12X5SB
- Type: Single-acting spring return cylinder (rod type)
- Bore size: 12mm (ISO 6432 standard)
- Stroke: 5mm ±0.5mm (adjustable cushioning)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -10℃ to 70℃
- Port size: M5x0.8 (dual ports for flexible piping)
- Cushion type: Rubber buffer + adjustable needle valve
- Mounting style: Free mount with 4x M3 threaded side holes
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel SUS304
- Seal material: NBR (nitrile rubber) with wear-resistant ring
- Weight: 98g ±2g (excluding accessories)
- Dimensions: 48mm(L) × 20mm(W) × 20mm(H) (body only)
- Stroke tolerance: +1.0mm/-0mm
- Max theoretical force: 8.1N at 0.5MPa
- Protection rating: IP40 (dust protected)
Ultra-compact cylinder with space-saving design (40% smaller than standard ISO cylinders), featuring dual lateral air ports for flexible piping arrangements. Precision-ground rod with chrome plating ensures smooth operation and corrosion resistance. Integrated mounting slots allow direct installation without brackets, compatible with DIN rail mounting adapters (optional). Includes built-in auto switch groove for sensor compatibility.
- Precision alignment mechanisms in semiconductor handling equipment
- Clamping devices for PCB assembly robots
- Miniature sorting gates in pharmaceutical packaging lines
- Valve actuators in portable analytical instruments
- Paper feed mechanisms in compact printers
Installation notes:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain 0.5mm minimum clearance between rod end and workpiece.
For vertical mounting, use spring-side port as default air inlet.
- Max speed: 500mm/s (with proper cushioning adjustment)
- Air consumption: 0.15L/min (ANR) at 0.5MPa
- Cycle life: 5,000km travel distance (under standard conditions)
| Property | Property Value |
|---|---|
| sku | MSUR12X5SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <5mm> |
