Description
1. Compliant with JIS (Japanese Industrial Standards) specifications;
2. Features four-directional mounting capability for flexible installation;
3. Space-saving gang-mounting design allows multiple cylinder combination;
4. Integrated guide boss ensures precise positioning alignment;
5. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and longevity;
6. Optional magnetic piston version enables position detection functionality;
7. Pre-machined T-slots on cylinder body facilitate adjustable sensor switch mounting;
8. Patented asymmetrical bidirectional sealing structure with compact profile and integrated lubrication reservoir.
Category: Compact Body Cylinder , Brand: AirTAC , Series: MSUR
Installation guidelines:
Apply silicone-free lubricant (ISO VG32 equivalent) during assembly.
Avoid side load exceeding 2N. For vertical mounting, use rod-down orientation
to prevent moisture accumulation. Replace seals after 3 million cycles or
3 years (whichever comes first) in continuous operation.
2. Features four-directional mounting capability for flexible installation;
3. Space-saving gang-mounting design allows multiple cylinder combination;
4. Integrated guide boss ensures precise positioning alignment;
5. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and longevity;
6. Optional magnetic piston version enables position detection functionality;
7. Pre-machined T-slots on cylinder body facilitate adjustable sensor switch mounting;
8. Patented asymmetrical bidirectional sealing structure with compact profile and integrated lubrication reservoir.
Category: Compact Body Cylinder , Brand: AirTAC , Series: MSUR
AirTAC MSUR Series Compact Cylinder MSUR16X10B Technical Details
- Model: MSUR16X10B
- Type: Double-acting, compact free mount cylinder
- Bore size: 16mm
- Stroke: 10mm (±1mm tolerance)
- Operating pressure: 0.15-0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Port size: M5x0.8 threaded
- Mounting type: Axial 4-hole pattern with 14mm spacing
- Material:
- Cylinder tube: Aluminum alloy, hard anodized
- End caps: Aluminum alloy
- Piston rod: Stainless steel SUS304
- Seals: NBR (Nitrile rubber)
- Weight: 0.12kg (excluding accessories)
- Dimensions:
- Length: 90mm (minimum compact length)
- Width: 34mm (mounting base width)
- Height: 34mm (mounting base height)
- Piston rod thread: M5x0.8 external thread
- Max theoretical force: 13.5N at 0.5MPa
- ISO standard: 6432 compliant (compact series)
Ultra-compact cylinder designed for space-constrained automation systems requiring precise linear motion. Features a maintenance-free design with corrosion-resistant construction and integrated mounting slots for tool-free installation. Optimized for high cycle rates up to 5 cycles/second with proper lubrication.
Ideal Applications:
- PCB handling robots in electronics manufacturing
- Micro-dosing mechanisms in medical devices
- Clamping fixtures for small CNC workholding
- Valve actuators in portable analytical instruments
- Paper feed mechanisms in compact printers
Installation guidelines:
Apply silicone-free lubricant (ISO VG32 equivalent) during assembly.
Avoid side load exceeding 2N. For vertical mounting, use rod-down orientation
to prevent moisture accumulation. Replace seals after 3 million cycles or
3 years (whichever comes first) in continuous operation.
| Property | Property Value |
|---|---|
| sku | MSUR16X10B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
