Description
1. Compliant with JIS (Japanese Industrial Standards) specifications;
2. Features four-directional mounting capability for flexible installation;
3. Space-saving gang-mounting design allows multiple cylinder combination;
4. Integrated guide boss ensures precise positioning alignment;
5. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and longevity;
6. Optional magnetic piston version enables position detection functionality;
7. Pre-machined T-slots on cylinder body facilitate adjustable sensor switch mounting;
8. Patented asymmetrical bidirectional sealing structure with compact profile and integrated lubrication reservoir.
Category: Compact Body Cylinder , Brand: AirTAC , Series: MSUR
Installation guidance:
Maintain 0.5-1mm clearance between cylinder body and mounting surface for thermal expansion.
For vertical mounting, use auxiliary rod-end support when stroke exceeds 50mm.
Lubricate with ISO VG32 turbine oil if non-lubricated air is used.
2. Features four-directional mounting capability for flexible installation;
3. Space-saving gang-mounting design allows multiple cylinder combination;
4. Integrated guide boss ensures precise positioning alignment;
5. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and longevity;
6. Optional magnetic piston version enables position detection functionality;
7. Pre-machined T-slots on cylinder body facilitate adjustable sensor switch mounting;
8. Patented asymmetrical bidirectional sealing structure with compact profile and integrated lubrication reservoir.
Category: Compact Body Cylinder , Brand: AirTAC , Series: MSUR
AirTAC MSUR Series Miniature Free Mount Cylinder MSUR16X5B Specifications
- Model: MSUR16X5B
- Bore size: 16mm
- Stroke: 5mm (Customizable up to 100mm)
- Operating pressure: 0.05–0.9 MPa
- Operating medium: Dry air (Lubricated operation requires oil mist lubrication)
- Ambient temperature: -20℃ to 80℃
- Cushion type: Rubber buffer + adjustable cushioning
- Mounting style: Basic type (Free mounting with optional accessories)
- Port size: M5x0.8 (Standard) / NPT1/8 (Optional)
- Piston material: Aluminum alloy hard anodized
- Rod material: Stainless steel SUS304
- Seal material: NBR (Standard) / PU (High wear resistance option)
- Weight: 0.25kg ±5% (Without accessories)
- Dimensions: 80mm(L) × 40mm(W) × 40mm(H) (Fully retracted position)
- Max theoretical thrust: 32.2N @0.5MPa
- ISO standard: Compliant with ISO 6432 (Miniature cylinders)
Ultra-compact cylinder designed for space-constrained automation systems. Features dual cushioning system with adjustable end-of-stroke deceleration and corrosion-resistant construction. Optional magnetic piston version (MSUR16X5B-M) for position sensing. Compatible with ISO 6432 mounting accessories.
Typical Applications:
- PCB handling robots in electronics assembly
- Precision clamping mechanisms in optical lens production
- Medical device actuation systems
- Compact packaging machine ejectors
- Laboratory automation sample handlers
- Automotive HVAC damper controls
- 3D printer component positioning
Installation guidance:
Maintain 0.5-1mm clearance between cylinder body and mounting surface for thermal expansion.
For vertical mounting, use auxiliary rod-end support when stroke exceeds 50mm.
Lubricate with ISO VG32 turbine oil if non-lubricated air is used.
| Property | Property Value |
|---|---|
| sku | MSUR16X5B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 16mm |
| Stroke | <5mm> |
