Description
1. Compliant with JIS (Japanese Industrial Standards) specifications;
2. Features four-directional mounting capability for flexible installation;
3. Space-saving gang-mounting design allows multiple cylinder combination;
4. Integrated guide boss ensures precise positioning alignment;
5. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and longevity;
6. Optional magnetic piston version enables position detection functionality;
7. Pre-machined T-slots on cylinder body facilitate adjustable sensor switch mounting;
8. Patented asymmetrical bidirectional sealing structure with compact profile and integrated lubrication reservoir.
Category: Compact Body Cylinder , Brand: AirTAC , Series: MSUR
Installation note:
Maintain 0.5mm minimum clearance between cylinder body and adjacent components to prevent heat transfer.
Lubricate with ISO VG32 hydraulic oil if operating below 0.3 MPa.
Maximum side load: 3N at full extension.
2. Features four-directional mounting capability for flexible installation;
3. Space-saving gang-mounting design allows multiple cylinder combination;
4. Integrated guide boss ensures precise positioning alignment;
5. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and longevity;
6. Optional magnetic piston version enables position detection functionality;
7. Pre-machined T-slots on cylinder body facilitate adjustable sensor switch mounting;
8. Patented asymmetrical bidirectional sealing structure with compact profile and integrated lubrication reservoir.
Category: Compact Body Cylinder , Brand: AirTAC , Series: MSUR
AirTAC MSUR Series Compact Free Mount Cylinder MSUR20X10S Specifications
- Model: MSUR20X10S
- Type: Single-acting spring return cylinder
- Bore size: 20 mm
- Stroke: 10 mm (customizable up to 100mm)
- Operating pressure: 0.05–0.9 MPa
- Operating medium temperature: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer
- Mounting style: Free installation (non-guided)
- Port size: M5×0.8 (standard) or NPT1/8 optional
- Piston rod thread: M6×1.0
- Material: Aluminum alloy body, CR12MoV chrome-plated rod
- Seal material: Heat-resistant NBR
- Protection rating: IP40 (IP67 with optional rod cover)
- Weight: 0.24 kg (without accessories)
- Dimensions: 98mm(L) × 20mm(Bore) × 34mm(Height at mounting base)
Ultra-compact pneumatic cylinder featuring space-saving design with integrated mounting slots for flexible positioning. The chrome-plated piston rod incorporates a wear-resistant coating (3-5μm thickness) for extended service life. Optimized air passage design reduces flow resistance by 15% compared to previous models.
Typical Applications:
- Precision clamping mechanisms in CNC tool changers
- Paper feed actuators in office automation equipment
- Valve actuation in semiconductor wafer handling systems
- Compact door operators in medical sterilization chambers
- Positioning stages in optical inspection devices
Installation note:
Maintain 0.5mm minimum clearance between cylinder body and adjacent components to prevent heat transfer.
Lubricate with ISO VG32 hydraulic oil if operating below 0.3 MPa.
Maximum side load: 3N at full extension.
Fluid Requirements:
Use filtered air with 5-40μm filtration accuracy.
Maintain dew point at least 5℃ below ambient temperature.
Oil mist lubrication recommended (ISO VG32 at 1/3000 ratio).
| Property | Property Value |
|---|---|
| sku | MSUR20X10S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
