Airtac MTAL Rear Single Acting Mini Cylinder MTAL20X15SU
1. Features precision-engineered aluminum alloy cylinder tube with optimized structural design;
2. Front/rear end caps adopt threaded connection for enhanced integrity;
3. Asymmetric bidirectional sealing structure on piston ensures compact dimensions with integrated oil reservoir functionality;
4. Front end incorporates self-lubricating bushings for superior guidance and lubrication performance;
5. Multiple rear mounting configurations enable flexible installation solutions;
6. Comprehensive selection of cylinder accessories and standard mounting kits available for customized applications.
Category: Mini Cylinders | Brand: Airtac | Series: MTAL
AirTAC MTAL20X15SU Post-Single Acting Miniature Cylinder Specifications
- Model: MTAL20X15SU
- Type: Post-single acting (spring return)
- Bore size: 20mm
- Stroke: 15mm (±1mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Port thread: M5×0.8 (standard) or Rc1/8 optional
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Buffer type: Rubber cushion (both ends)
- Mounting type: Rod side flange (standard ISO 6432)
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (nitrile rubber)
- Protection rating: IP65 (dust-tight & water jet resistant)
- Weight: 0.22kg (without accessories)
- Dimensions: 80mm(L) × 20mm(W) × 25mm(H) (fully retracted)
Ultra-compact pneumatic cylinder optimized for space-constrained automation systems. Features anodized aluminum barrel for corrosion resistance and smooth operation. The spring-return mechanism provides reliable position recovery in power-off situations. Requires 0.5μm filtered air with ISO VG32 hydraulic oil mist lubrication (1 drop/cycle recommended).
- PCB handling robots in electronics assembly
- Precision clamping in CNC tool changers
- Valve actuation in medical analyzers
- Sorting gates in pharmaceutical packaging lines
- Camera module positioning in optical equipment
Installation note:
Lubricate rod with silicone grease (AS-20) before initial use.
Avoid side load exceeding 2N·m. Maximum permissible lateral
rod-end play: 0.3mm. For vertical mounting, use M3×8 screws
with 0.6N·m torque.
| Property | Property Value |
|---|---|
| sku | MTAL20X15SU |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <15mm> |
