Airtac MTBL Single Acting Aluminum Alloy Mini Cylinder MTBL20X100CA
2. Features riveted aluminum-clad structure for secure connection between end covers and alloy barrel;
3. Utilizes custom bidirectional sealing structure on piston for compact design with integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced installation flexibility;
5. Comprehensive range of cylinder specifications and mounting accessories available for selection.
Category: Aluminum Mini Cylinders | Brand: AIRTAC | Series: MTBL Single-Acting
AirTAC MTBL20X100CA Single-Acting Aluminum Mini Cylinder Specifications
- Model: MTBL20X100CA
- Type: Single-acting spring return (compressed air actuation)
- Bore size: 20mm
- Stroke: 100mm
- Operating pressure: 0.15–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Port size: M5x0.8 (standard) or NPT1/8 (optional)
- Cushioning: Adjustable rubber cushion at both ends
- Mounting style: Basic type (axial mounting holes)
- Material: Aluminum alloy body, NBR seals
- Weight: ~0.45kg (without accessories)
- Dimensions: 150mm(L) × 32mm(W) × 32mm(H) (full extension)
- Piston rod thread: M5x0.8 (external thread)
- Max theoretical force: 62.8N at 0.6MPa
- Air consumption: 3.14cm³/stroke
- ISO standard: Compliant with ISO 6432
Ultra-compact aluminum cylinder designed for space-constrained automation systems. Features precision-machined guide bands for smooth operation and anti-rotation piston rod. The spring-return mechanism ensures fail-safe retraction during air pressure loss. Pre-lubricated for maintenance-free operation in clean environments.
- Precision clamping in CNC tool changers
- Valve actuation in medical equipment
- Paper feed mechanisms in office automation
- Component positioning in semiconductor handlers
- Door locking systems in cleanroom environments
Installation note:
Maintain alignment tolerance ≤0.2mm during mounting. Use flexible couplings when lateral forces exceed 2N.
For vertical mounting, consider adding 10-15% extra pressure to compensate for spring force.
| Property | Property Value |
|---|---|
| sku | MTBL20X100CA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
