Airtac MTBL Single Acting Aluminum Alloy Mini Cylinder MTBL20X100SCA
2. Features riveted aluminum-clad structure for secure connection between end covers and alloy barrel;
3. Utilizes custom bidirectional sealing structure on piston for compact design with integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced installation flexibility;
5. Comprehensive range of cylinder specifications and mounting accessories available for selection.
Category: Aluminum Mini Cylinders | Brand: AIRTAC | Series: MTBL Single-Acting
AirTAC MTBL Single-Acting Aluminum Mini Cylinder MTBL20X100SCA Specifications
- Model: MTBL20X100SCA
- Type: Single-acting spring return (miniature series)
- Bore size: 20mm
- Stroke: 100mm
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -10℃ to 80℃
- Port size: M5x0.8 (dual ports)
- Cushioning: Rubber buffer (adjustable end cushion)
- Mounting style: Foot-mounted with 4xM5 threaded holes
- Seal material: NBR + PUR hybrid seals
- Weight: 580g ±2%
- Dimensions: 150mm(L) × 34mm(W) × 34mm(H)
- Rod thread: M6x1.0 external thread
- Max speed: 500mm/s
- Lubrication: Pre-lubricated (recommended relubrication every 500km)
Ultra-compact aluminum cylinder optimized for space-constrained automation systems. Features wear-resistant anodized surface treatment and integrated air-saving design. The SCA variant includes enhanced lateral load capacity (up to 15N side force) through reinforced rod guidance. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.4.2 air quality.
- PCB handling robots in electronics manufacturing
- Precision dosing valves in pharmaceutical packaging
- Automated test equipment probe positioning
- Cleanroom wafer transfer mechanisms
- Compact food processing actuators (FDA-compliant grease option available)
Installation note:
Use flexible couplings to compensate for misalignment (max 0.5° angular tolerance).
For vertical mounting, reduce payload capacity by 20%. Lubricate through air supply
using ISO VG32 turbine oil mist at 1/30,000 ratio.
| Property | Property Value |
|---|---|
| sku | MTBL20X100SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
